Stainless Steel Deep Groove Ball Bearings D/W R2-6-2Z

Stainless Steel Deep Groove Ball Bearings D/W R2-6-2Z

The D/W R2-6-2Z is a compact stainless steel deep groove ball bearing, measuring just 0.125″ by 0.375″ by 0.14059″. It handles radial loads up to 82 lbf and spins smoothly at speeds up to 63,000 RPM.

Its shielded design keeps grease in and dirt out, while the all-stainless construction resists corrosion. The bearing performs well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for small instruments or precision devices where space is limited.

Weighing only 0.0011kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W R2-6-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 0.125"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.375"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.14059"
  • Width Tolerance -0.005" to 0"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 82 lbf
  • Static Radial Load 26 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 63000 rpm
  • Weight 0.0011 kg
Stainless Steel Deep Groove Ball Bearings D/W R2-6-2Z dimension drawing
Download DWG Download PDF

Features

How Does D/W R2-6-2Z Bearing Reduce Friction?

D/W R2-6-2Z Bearing is crafted with stainless steel rings and balls, ensuring smooth operation with minimal friction.
Its shielded design protects against contaminants, maintaining consistent performance in radial load applications.
The grease lubrication enhances durability, allowing it to handle speeds up to 63,000 rpm.
With a dynamic radial load capacity of 82 lbf, it offers reliable performance in compact spaces.

Application

Industrial Uses of D/W R2-6-2Z Bearing
D/W R2-6-2Z Bearing is commonly used in small industrial equipment like precision instruments and compact machinery, where its shielded design helps keep contaminants out.
The stainless steel construction makes it suitable for environments where corrosion resistance is important, such as food processing or chemical handling.

Where Is D/W R2-6-2Z Bearing Used?
You’ll often find D/W R2-6-2Z Bearing in medical devices like dental tools or lab equipment, thanks to its smooth operation and reliable performance.
Its small size and inch measurements make it a good fit for applications requiring precise radial load support in tight spaces.

Perfect Fit for Automation: D/W R2-6-2Z Bearing
In robotic arms and small automation systems, D/W R2-6-2Z Bearing provides consistent movement with minimal maintenance.
The grease lubrication ensures quiet operation, which is ideal for sensitive environments like laboratories or clean rooms.

Light-Duty vs Heavy-Duty: Best Uses for D/W R2-6-2Z Bearing
For light-duty applications like small fans or printers, D/W R2-6-2Z Bearing offers durability without adding unnecessary weight.
In more demanding settings, its stainless steel build handles moderate radial loads while resisting wear over time.

How Does D/W R2-6-2Z Bearing Support High-Speed Operations?
With a max speed of 63,000 rpm, D/W R2-6-2Z Bearing works well in high-speed devices like small motors or spindle drives.
The shielded design helps maintain performance by reducing friction and keeping the grease in place during rapid rotation.
