Spherical Roller Thrust Bearings 29324 E

Spherical Roller Thrust Bearings 29324 E

The 29324 E is a spherical roller thrust bearing with a 120mm bore and 210mm outer diameter, crafted from sturdy steel for durability. It handles combined loads up to 171,979 lbf and operates smoothly at speeds up to 2800 RPM.

Its single-row design with steel rollers and cage ensures reliable performance under heavy loads. The bearing requires regular lubrication and works in temperatures from -30°C to 100°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy machinery or industrial equipment where combined loads are common.

Weighing 7.35kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 29324 E
  • Brand TFL
  • Interchangeable SKF
  • Size 120 mm x 210 mm x 54 mm
  • Bore Dia 120 mm
  • Bore Dia Tolerance -0.025 to 0
  • Outer Dia 210 mm
  • Outer Dia Tolerance -0.03 to 0
  • Width 54 mm
  • Outside Diameter(d1) 188 mm
  • Shoulder Diameter Outer Ring (D1) 155 mm
  • Height Shaft Washer Cage(B1) 48.2 mm
  • Height Housing Washer(C) 27 mm
  • Distance From Shaft Washer End Side Face To Pressure Point(s) 70 mm
  • Chamfer Dimension Shaft Washer(r1,2) 2.1 mm
  • System of Measurement Metric
  • Roller Bearing Type Spherical
  • Bearing Type Roller
  • For Load Direction Combined
  • Construction Single Row
  • Roller Material Steel
  • Cage Material Steel
  • Dynamic Thrust Load 171979 lbf
  • Static Thrust Load 476595 lbf
  • Max Speed 2800 rpm
  • Lubrication Required
  • Temperature Range -30 to 100 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 7.35 kg
  • Height Tolerance -0.125 to 0
  • Width Shaft Washer Or Length Of Shaft(B) 34 mm
  • Price（$） 422.55

Features

Performance Features of 29324 E Bearing

29324 E Bearing is built with steel rollers and cage, offering robust performance under combined loads.
Its dynamic thrust load capacity reaches 171,979 lbf, making it suitable for heavy-duty applications.

The spherical roller design ensures smooth operation even with misalignment, enhancing reliability.
With a maximum speed of 2,800 rpm, it balances efficiency and durability in demanding conditions.

29324 E Bearing operates in temperatures from -30°C to 100°C, adapting to various environments.
Its precise dimensions and tolerances ensure easy installation and consistent performance.

Application

Industrial Uses of 29324 E Bearing
29324 E Bearing is commonly used in heavy machinery like mining equipment and crushers, where its spherical roller design handles combined loads effectively. The steel construction ensures durability even in demanding environments.

Where Is 29324 E Bearing Used?
You’ll often find 29324 E Bearing in wind turbines and gearboxes, where its high dynamic thrust load capacity keeps things running smoothly. Its metric sizing makes it a versatile choice for various industrial applications.

Built for Heavy-Duty Use: 29324 E Bearing
29324 E Bearing excels in applications like conveyor systems and marine propulsion, thanks to its robust steel rollers and cage. The wide temperature range also makes it suitable for both hot and cold environments.

Automotive vs Aerospace: Applications of 29324 E Bearing
In automotive systems, 29324 E Bearing supports heavy-duty transmissions, while in aerospace, it’s used in landing gear mechanisms. Its high static thrust load capacity ensures reliability in both fields.

Practical Applications of 29324 E Bearing
29324 E Bearing is a go-to for construction equipment like cranes and bulldozers, where its combined load handling shines. The lubrication requirement is easily met with standard industrial greases.
