Spherical Roller Thrust Bearings 29240 E

Spherical Roller Thrust Bearings 29240 E

The 29240 E is a spherical roller thrust bearing with a 200mm bore and 280mm outer diameter, designed to handle combined loads. It’s built from sturdy steel, offering a dynamic thrust load capacity of 147475 lbf and a static thrust load of 595744 lbf.

Its spherical roller design allows for smooth rotation even under heavy loads, with a maximum speed of 2200 RPM. The steel cage ensures durability, while the single-row construction simplifies installation.

This bearing requires regular lubrication and operates efficiently in temperatures from -30°C to 100°C. It’s interchangeable with SKF bearings, making it a practical choice for replacements.

Weighing 9.3kg, it’s robust yet manageable for its size. Ideal for heavy-duty applications like industrial machinery or construction equipment where combined loads are common. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 29240 E
  • Brand TFL
  • Interchangeable SKF
  • Size 200 mm x 280 mm x 48 mm
  • Bore Dia 200 mm
  • Bore Dia Tolerance -0.03 to 0
  • Outer Dia 280 mm
  • Outer Dia Tolerance -0.035 to 0
  • Width 48 mm
  • Outside Diameter(d1) 260 mm
  • Shoulder Diameter Outer Ring (D1) 233 mm
  • Height Shaft Washer Cage(B1) 43.4 mm
  • Height Housing Washer(C) 24 mm
  • Distance From Shaft Washer End Side Face To Pressure Point(s) 108 mm
  • Chamfer Dimension Shaft Washer(r1,2) 2 mm
  • System of Measurement Metric
  • Roller Bearing Type Spherical
  • Bearing Type Roller
  • For Load Direction Combined
  • Construction Single Row
  • Roller Material Steel
  • Cage Material Steel
  • Dynamic Thrust Load 147475 lbf
  • Static Thrust Load 595744 lbf
  • Max Speed 2200 rpm
  • Lubrication Required
  • Temperature Range -30 to 100 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 9.3 kg
  • Width Shaft Washer Or Length Of Shaft(B) 30 mm
  • Price（$） 754.227

Features

How Is 29240 E Bearing Engineered for Reliability?

29240 E Bearing is constructed with steel rollers and cage, ensuring strength under combined loads.
Its dynamic thrust load capacity of 147475 lbf makes it suitable for heavy-duty applications.

The spherical roller design allows for smooth operation even under misalignment conditions.
With a maximum speed of 2200 rpm, it maintains performance in demanding environments.

29240 E Bearing operates within a temperature range of -30 to 100°C, providing versatility.
Its robust construction reduces maintenance needs, enhancing long-term reliability.

Application

Industrial Uses of 29240 E Bearing
In heavy machinery like crushers and mining equipment, 29240 E Bearing handles combined loads with ease, thanks to its spherical roller design. The steel construction ensures durability even in demanding environments.

Where Is 29240 E Bearing Used?
You’ll often find 29240 E Bearing in gearboxes and large industrial fans, where its high dynamic thrust load capacity keeps things running smoothly. Its metric sizing makes it a versatile choice for various applications.

Built for Heavy-Duty Use: 29240 E Bearing
29240 E Bearing excels in applications like marine propulsion systems, where its ability to handle both radial and axial loads is crucial. The steel cage adds extra strength for long-lasting performance.

Automotive vs Aerospace: Applications of 29240 E Bearing
In automotive settings, 29240 E Bearing supports heavy transmissions, while in aerospace, it’s used in auxiliary systems. Its temperature range and load capacity make it adaptable across industries.

Practical Applications of 29240 E Bearing
For conveyor systems in factories, 29240 E Bearing offers reliable performance under constant load. The single-row design simplifies maintenance, making it a practical choice for continuous operation.
