Snap Ring Groove Ball Bearings 6310-2RS1NR

Snap Ring Groove Ball Bearings 6310-2RS1NR

The 6310-2RS1NR is a sealed snap ring groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from robust chrome steel. It handles radial loads up to 13938 lbf and operates smoothly at speeds up to 6000 RPM.

Its sealed design keeps dirt out and grease in, reducing maintenance needs. The snap ring on the outer ring ensures secure fitting, making installation straightforward.

This bearing is compatible with SKF models, offering a reliable alternative. It performs well in temperatures from -30°C to 120°C, suitable for various industrial applications.

Weighing 1050g, it’s sturdy yet manageable. Compliant with RoHS and REACH standards, it’s a safe choice for machinery and equipment.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6310-2RS1NR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 116.6 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 13938 lbf
  • Static Radial Load 861 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6000 rpm
  • Weight 1050 g
  • Price（$） 18.92
Snap Ring Groove Ball Bearings 6310-2RS1NR dimension drawing
Download DWG Download PDF

Features

Built for Reliability: 6310-2RS1NR Bearing

6310-2RS1NR Bearing features a sealed design, protecting against dust and moisture for consistent performance.
The chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 13938 lbf, it handles heavy-duty tasks with ease.
The snap ring groove provides secure mounting, reducing the risk of misalignment during operation.

Its temperature range of -30° to 120°C makes it suitable for various industrial environments.
The ABEC 1 tolerance ensures reliable precision without compromising on cost-effectiveness.

Application

Common Applications of 6310-2RS1NR Bearing
6310-2RS1NR Bearing is widely used in industrial machinery, such as conveyor systems and electric motors, where its sealed design helps keep contaminants out. The snap ring feature ensures easy installation and secure positioning in housings.

In automotive applications, 6310-2RS1NR Bearing is often found in wheel hubs and transmissions, providing reliable radial load support. Its chrome steel construction offers durability under various driving conditions.

For automation equipment, 6310-2RS1NR Bearing works well in robotic arms and assembly lines, thanks to its smooth operation and low maintenance needs. The sealed design also makes it suitable for dusty or wet environments.

In household appliances like washing machines, 6310-2RS1NR Bearing ensures quiet and efficient performance. Its robust design handles the constant motion and load changes typical in these devices.
