Snap Ring Groove Ball Bearings 6309-2RSNR

Snap Ring Groove Ball Bearings 6309-2RSNR

The 6309-2RSNR is a sealed snap ring groove ball bearing with a 45mm bore and 100mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 11915 lbf and operates smoothly at speeds up to 6700 RPM.

Its sealed design keeps dirt out and grease in, reducing maintenance needs. The snap ring on the outer ring ensures secure fitting, making installation straightforward.

This bearing is interchangeable with SKF models, offering a reliable replacement option. It performs well in temperatures from -30°C to 120°C, suitable for various industrial applications.

Weighing 811g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for most environments. Ideal for machinery where radial loads and secure mounting are key.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6309-2RSNR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 25 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 106.5 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 11915 lbf
  • Static Radial Load 7194 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6700 rpm
  • Weight 811 g
  • Price（$） 22.6
Snap Ring Groove Ball Bearings 6309-2RSNR dimension drawing
Download DWG Download PDF

Features

Why Choose 6309-2RSNR Bearing for Precision Tasks?

6309-2RSNR Bearing features a sealed design, protecting against dust and contaminants for consistent performance.
Its chrome steel construction ensures durability and resistance to wear, even under high radial loads.
The snap ring on the outer ring simplifies installation, making it ideal for precision applications.
With a maximum speed of 6,700 rpm, it balances efficiency and reliability in demanding conditions.

Application

Common Applications of 6309-2RSNR Bearing
6309-2RSNR Bearing is widely used in industrial machinery, such as pumps and gearboxes, where its sealed design helps keep contaminants out. The snap ring feature ensures easy installation and secure positioning in housings.

In automotive applications, 6309-2RSNR Bearing is often found in wheel hubs and transmissions, providing reliable radial load support. Its chrome steel construction offers durability under various driving conditions.

For automation systems, 6309-2RSNR Bearing works well in robotic arms and conveyor belts, thanks to its smooth operation and low maintenance needs. The sealed design also makes it suitable for dusty environments.

In household appliances like washing machines, 6309-2RSNR Bearing ensures quiet and efficient performance. Its robust build can handle the constant motion and load changes typical in these devices.
