Snap Ring Groove Ball Bearings 6308-ZNR

Snap Ring Groove Ball Bearings 6308-ZNR

The 6308-ZNR is a shielded ball bearing with a 40mm bore and 90mm outer diameter, designed for radial loads. It’s built from chrome steel for durability and can handle dynamic loads up to 9509 lbf.

With a snap ring groove on the outer ring, it stays securely in place during operation. The stainless steel cage ensures smooth rotation, even at speeds up to 11,000 RPM.

This bearing works well in temperatures from -30°C to 120°C and comes pre-lubricated with grease for easy maintenance. It’s interchangeable with SKF models, making replacements straightforward.

Ideal for machinery where radial loads and secure positioning are key, such as pumps or electric motors. Weighing 0.65kg, it’s a sturdy yet manageable choice for industrial applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6308-ZNR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.12mm to 0
  • Outside Diameter Of Snap Ring 96.5 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 9509 lbf
  • Static Radial Load 5395 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 0.65 kg
Snap Ring Groove Ball Bearings 6308-ZNR dimension drawing
Download DWG Download PDF

Features

How Does 6308-ZNR Bearing Reduce Friction?

6308-ZNR Bearing features chrome steel rings and balls, designed to minimise friction during operation.
The shielded design helps keep contaminants out, ensuring smoother performance over time.

With a dynamic radial load capacity of 9509 lbf, it handles demanding radial loads efficiently.
The stainless steel cage maintains ball alignment, reducing wear and extending bearing life.

Its maximum speed of 11,000 rpm makes it suitable for high-speed applications.
The snap ring groove adds stability, making installation and positioning easier.

Application

Industrial Uses of 6308-ZNR Bearing
The 6308-ZNR Bearing is commonly used in industrial machinery like pumps and gearboxes, where its shielded design helps keep contaminants out. Its snap ring feature ensures secure mounting, making it ideal for high-vibration environments.

Where Is 6308-ZNR Bearing Used?
You’ll often find the 6308-ZNR Bearing in automotive applications, such as alternators and transmission systems. Its grease lubrication and chrome steel construction provide long-lasting performance even under heavy radial loads.

Built for Heavy-Duty Use: 6308-ZNR Bearing
In automation equipment like conveyor belts, the 6308-ZNR Bearing offers reliable operation thanks to its stainless steel cage. The metric sizing makes it easy to integrate into various European and Asian machinery designs.

Automotive vs Industrial: Applications of 6308-ZNR Bearing
While the 6308-ZNR Bearing excels in car components like wheel hubs, it’s also a staple in industrial fans. Its temperature range of -30° to 120°C ensures versatility across different operating conditions.
