Snap Ring Groove Ball Bearings 6212-ZNR JEM

Snap Ring Groove Ball Bearings 6212-ZNR JEM

The 6212-ZNR JEM is a shielded ball bearing with a 60mm bore and 110mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 1178 lbf and operates smoothly at speeds up to 5600 RPM.

Its snap ring groove on the outer ring ensures secure fitting, while the shielded design keeps contaminants out. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for machinery where radial loads and secure mounting are key, such as electric motors or conveyor systems.

Weighing 762g, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6212-ZNR JEM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.150mm to 0
  • Outside Diameter Of Snap Ring 101.6 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1178 lbf
  • Static Radial Load 8138 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 762 g
  • Price（$） 21.8
Snap Ring Groove Ball Bearings 6212-ZNR JEM dimension drawing
Download DWG Download PDF

Features

Why Choose 6212-ZNR JEM Bearing for Precision Tasks?

6212-ZNR JEM Bearing features a shielded design, protecting against contaminants while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.
With a snap ring groove on the outer ring, it offers secure mounting and easy installation.
The bearing handles dynamic radial loads up to 1178 lbf, making it suitable for various industrial uses.
Operating at temperatures from -30°C to 120°C, it performs reliably in diverse environments.
Its ABEC 1 tolerance class provides consistent precision for demanding tasks.

Application

Common Applications of 6212-ZNR JEM Bearing
The 6212-ZNR JEM Bearing is widely used in industrial machinery like pumps and gearboxes, where its shielded design helps keep contaminants out. The snap ring feature ensures secure mounting, making it ideal for high-vibration environments.

In automotive applications, 6212-ZNR JEM Bearing fits well in wheel hubs and transmission systems, thanks to its radial load capacity. Its chrome steel construction offers durability, even under frequent use.

For automation equipment, 6212-ZNR JEM Bearing provides reliable performance in robotic arms and conveyor belts. The ABEC 1 tolerance ensures smooth operation, which is essential for precision tasks.

Around the home, you might find 6212-ZNR JEM Bearing in appliances like washing machines, where its shielded design helps extend service life. The snap ring also simplifies installation, saving time during maintenance.
