Snap Ring Groove Ball Bearings 6212-2RS1NR

Snap Ring Groove Ball Bearings 6212-2RS1NR

The 6212-2RS1NR is a sealed snap ring groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1178 lbf and operates smoothly at speeds up to 5600 RPM.

Its sealed design keeps out dust and moisture, while the snap ring ensures secure fitting. The chrome steel cage adds durability, making it suitable for long-term use in various conditions.

This bearing works well in temperatures from -30°C to 120°C and is interchangeable with SKF models. Ideal for applications like electric motors or pumps where reliable radial load support is needed.

Weighing 762g, it’s a robust choice for industrial machinery. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6212-2RS1NR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.150mm to 0
  • Outside Diameter Of Snap Ring 101.6 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1178 lbf
  • Static Radial Load 8138 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 762 g
  • Price（$） 24.78
Snap Ring Groove Ball Bearings 6212-2RS1NR dimension drawing
Download DWG Download PDF

Features

How Does 6212-2RS1NR Bearing Reduce Friction?

6212-2RS1NR Bearing features a sealed design with chrome steel rings and balls, ensuring smooth operation and reduced friction.
The snap ring groove on the outer ring provides secure fitting, enhancing stability during high-speed rotation.
With a dynamic radial load capacity of 1178 lbf, it handles demanding radial loads efficiently.
Its temperature range of -30° to 120°C makes it suitable for various operating conditions.

Application

Common Applications of 6212-2RS1NR Bearing
The 6212-2RS1NR Bearing is widely used in industrial machinery, especially in conveyor systems and gearboxes, where its sealed design helps keep contaminants out. Its snap ring feature ensures easy installation and secure positioning in housings.

In automotive applications, 6212-2RS1NR Bearing is often found in wheel hubs and transmissions, providing reliable radial load support. The chrome steel construction offers durability, even under constant use.

For home appliances like washing machines, 6212-2RS1NR Bearing’s sealed design prevents dust and moisture from affecting performance. Its compact size and robust build make it a dependable choice for everyday use.

The 6212-2RS1NR Bearing also works well in small electric motors, where its low maintenance requirements are a plus. The ABEC 1 tolerance ensures smooth operation without needing frequent adjustments.
