Snap Ring Groove Ball Bearings 6211-ZNR/C3

Snap Ring Groove Ball Bearings 6211-ZNR/C3

The 6211-ZNR/C3 is a shielded, single-row ball bearing with a 55mm bore and 100mm outer diameter, designed for radial loads. It’s built from chrome steel for durability and handles loads up to 9757 lbf, with a maximum speed of 6300 RPM.

Its snap ring groove on the outer ring ensures secure fitting, while the C3 radial clearance allows for thermal expansion. The shielded design keeps contaminants out, extending bearing life.

This model works in temperatures from -30°C to 120°C and is interchangeable with SKF bearings. Ideal for electric motors or pumps where reliable radial load support is needed.

Weighing 599g, it’s a sturdy choice for industrial applications. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6211-ZNR/C3
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.150mm to 0
  • Outside Diameter Of Snap Ring 106.5 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 9757 lbf
  • Static Radial Load 6609 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 599 g
  • Price（$） 15.96
Snap Ring Groove Ball Bearings 6211-ZNR/C3 dimension drawing
Download DWG Download PDF

Features

How Does 6211-ZNR/C3 Bearing Reduce Friction?

6211-ZNR/C3 Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its shielded design protects against contaminants, maintaining performance in various environments.

The snap ring groove on the outer ring provides secure fitting, reducing vibration and wear.
With a dynamic radial load capacity of 9757 lbf, it handles heavy loads efficiently.

6211-ZNR/C3 Bearing operates at speeds up to 6,300 rpm, balancing durability and performance.
Its C3 radial clearance ensures reliable operation under varying temperature conditions.

Application

Common Applications of 6211-ZNR/C3 Bearing
You’ll often spot 6211-ZNR/C3 Bearing in conveyor systems, where its snap ring groove keeps it securely positioned during continuous operation. The shielded design helps keep contaminants out, extending service life in dusty environments.

Industrial Uses of 6211-ZNR/C3 Bearing
In electric motors, 6211-ZNR/C3 Bearing handles radial loads efficiently while the C3 clearance accommodates thermal expansion. Its chrome steel construction stands up well to the vibrations common in motor applications.

Where to Use 6211-ZNR/C3 Bearing
Farm equipment benefits from 6211-ZNR/C3 Bearing’s durability when dealing with uneven loads and outdoor conditions. The snap ring feature prevents axial movement that could occur during rough terrain operation.

Practical Applications of 6211-ZNR/C3 Bearing
For workshop tools like bench grinders, 6211-ZNR/C3 Bearing offers smooth rotation at moderate speeds. The shielded design keeps grinding debris from affecting bearing performance over time.

Market Demand for 6211-ZNR/C3 Bearing
Pump manufacturers frequently choose 6211-ZNR/C3 Bearing for its reliable performance in wet environments. The corrosion-resistant materials and secure snap ring fitting make it suitable for various fluid handling systems.
