Snap Ring Groove Ball Bearings 6209-2RS1NR

Snap Ring Groove Ball Bearings 6209-2RS1NR

The 6209-2RS1NR is a sealed snap ring groove ball bearing with a 45mm bore and 85mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 7351 lbf and operates smoothly at speeds up to 7700 RPM.

Its sealed design keeps dirt out and grease in, while the snap ring on the outer ring ensures secure fitting. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 407g, it’s a sturdy yet manageable size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6209-2RS1NR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 85 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 19 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 91.6 mm
  • Width Of Snap Ring 1.7 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 7351 lbf
  • Static Radial Load 4564 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 7700 rpm
  • Weight 407 g
  • Price（$） 14.47
Snap Ring Groove Ball Bearings 6209-2RS1NR dimension drawing
Download DWG Download PDF

Features

Why Choose 6209-2RS1NR Bearing for Precision Tasks?

6209-2RS1NR Bearing features a sealed design, protecting it from dust and moisture for consistent performance.

Its chrome steel construction ensures durability and resistance to wear, even under heavy radial loads.

With a dynamic radial load capacity of 7351 lbf, it handles demanding applications with ease.

The snap ring groove on the outer ring provides secure mounting, reducing the risk of misalignment.

Application

Common Applications of 6209-2RS1NR Bearing
6209-2RS1NR Bearing is widely used in industrial machinery, such as conveyor belts and pumps, where its sealed design keeps contaminants out. The snap ring feature ensures secure mounting, making it ideal for high-vibration environments.

In automotive applications, 6209-2RS1NR Bearing supports components like alternators and water pumps, providing reliable radial load handling. Its chrome steel construction offers durability under constant use, ensuring long service life.

For automation systems, 6209-2RS1NR Bearing is a solid choice for robotic arms and assembly lines, where precision and low maintenance are key. The sealed design also helps in dusty or wet conditions, reducing wear over time.

In household appliances like washing machines, 6209-2RS1NR Bearing ensures smooth operation with minimal noise. Its snap ring design simplifies installation, making it a practical option for manufacturers.
