Snap Ring Groove Ball Bearings 6207-2RSNRJEM

Snap Ring Groove Ball Bearings 6207-2RSNRJEM

The 6207-2RSNRJEM is a sealed, single-row ball bearing with a 35mm bore and 72mm outer diameter, built from sturdy chrome steel. It handles radial loads up to 5778 lbf and spins smoothly at speeds up to 9200 RPM.

Its snap ring groove on the outer ring keeps it securely in place, while the sealed design protects against dust and dirt. The bearing performs well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads and secure mounting are needed.

Weighing 288g, it’s a compact yet durable option. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6207-2RSNRJEM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 78.6 mm
  • Width Of Snap Ring 1.7 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 5778 lbf
  • Static Radial Load 3462 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 9200 rpm
  • Weight 288 g
  • Price（$） 8.39
Snap Ring Groove Ball Bearings 6207-2RSNRJEM dimension drawing
Download DWG Download PDF

Features

How Does 6207-2RSNRJEM Bearing Reduce Friction?

6207-2RSNRJEM Bearing features a sealed design with chrome steel rings and balls, ensuring smooth operation with minimal friction.
The single-row construction and snap ring outer ring provide stability, making it ideal for radial load applications.
With a dynamic radial load capacity of 5778 lbf, it handles demanding conditions while maintaining efficiency.
Its maximum speed of 9,200 rpm and temperature range of -30° to 120°C make it versatile for various environments.

Application

Common Applications of 6207-2RSNRJEM Bearing
6207-2RSNRJEM Bearing is widely used in industrial machinery, especially in conveyor systems and electric motors, where its sealed design helps keep out dust and debris. The snap ring feature ensures secure mounting, making it ideal for high-vibration environments.

In automotive applications, 6207-2RSNRJEM Bearing supports components like alternators and water pumps, providing reliable performance under radial loads. Its chrome steel construction offers durability, even in demanding driving conditions.

For home appliances, 6207-2RSNRJEM Bearing is often found in washing machines and fans, where its sealed design reduces maintenance needs. The compact size and snap ring make it easy to install in tight spaces.

Automation systems benefit from 6207-2RSNRJEM Bearing in robotic arms and assembly lines, where smooth operation is essential. The ABEC 1 tolerance ensures consistent performance without unnecessary precision costs.

Medical devices like centrifuges use 6207-2RSNRJEM Bearing for its reliable rotation and low maintenance. The sealed design helps maintain cleanliness in sensitive environments.
