Snap Ring Groove Ball Bearings 6207-2RS1NR/W64

Snap Ring Groove Ball Bearings 6207-2RS1NR/W64

The 6207-2RS1NR/W64 is a sealed snap ring groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 5778 lbf and operates smoothly at speeds up to 9200 RPM.

Its sealed design keeps dirt out and solid oil lubrication ensures long service life. The snap ring on the outer ring makes installation secure and straightforward.

This bearing suits radial load applications like electric motors or pumps, where reliability is key. It performs well in temperatures from -30°C to 120°C.

Weighing 288g, it’s a sturdy yet lightweight option. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6207-2RS1NR/W64
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 78.6 mm
  • Width Of Snap Ring 1.7 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 5778 lbf
  • Static Radial Load 3462 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 9200 rpm
  • Weight 288 g
  • Price（$） 15.65
Snap Ring Groove Ball Bearings 6207-2RS1NR/W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6207-2RS1NR/W64 Bearing

6207-2RS1NR/W64 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 5778 lbf, ensuring reliable performance in various applications.

The sealed design and solid oil lubrication reduce maintenance needs while protecting against contaminants.
With a maximum speed of 9,200 rpm, it balances durability and efficiency.

The snap ring feature on the outer ring provides secure mounting, simplifying installation.
Its temperature range of -30°C to 120°C makes it suitable for diverse operating conditions.

Application

Common Applications of 6207-2RS1NR/W64 Bearing
6207-2RS1NR/W64 Bearing is widely used in industrial equipment like conveyor systems and electric motors, where its sealed design keeps out dust and debris. The snap ring feature ensures easy installation and secure positioning in housings.

In automotive applications, 6207-2RS1NR/W64 Bearing is found in gearboxes and wheel hubs, providing reliable radial load support. Its solid oil lubrication reduces maintenance needs, making it ideal for long-term use.

For automation systems, 6207-2RS1NR/W64 Bearing works well in robotic arms and assembly lines, thanks to its smooth operation and durability. The chrome steel construction handles high speeds without compromising performance.

In household appliances like washing machines, 6207-2RS1NR/W64 Bearing offers quiet and efficient operation. The sealed design prevents grease leakage, ensuring cleanliness in domestic environments.
