Snap Ring Groove Ball Bearings 6205-RSNBR

Snap Ring Groove Ball Bearings 6205-RSNBR

The 6205-RSNBR is a sealed snap ring groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13,000 RPM.

Its sealed design keeps dirt out and grease in, reducing maintenance needs, while the snap ring groove ensures secure fitting. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Perfect for applications like electric motors or conveyor systems where radial loads and secure mounting are key.

Weighing just 128g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-RSNBR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 52 mm
  • Width Of Snap Ring 1.35 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring Groove
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 128 g
  • Price（$） 4.11
Snap Ring Groove Ball Bearings 6205-RSNBR dimension drawing
Download DWG Download PDF

Features

Why Choose 6205-RSNBR Bearing for Precision Tasks?

6205-RSNBR Bearing features a sealed design, protecting it from dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

The snap ring groove on the outer ring allows for secure mounting, simplifying installation.
With a dynamic radial load capacity of 3147 lbf, it handles demanding conditions reliably.

Operating at speeds up to 13,000 rpm, 6205-RSNBR Bearing balances efficiency and longevity.
Its ABEC 1 tolerance class ensures smooth operation for precision tasks.

Application

Common Applications of 6205-RSNBR Bearing
The 6205-RSNBR Bearing is widely used in industrial machinery, especially in conveyor systems and electric motors, where its sealed design helps keep out dust and debris. Its snap ring groove ensures secure mounting, making it ideal for high-vibration environments.

In automotive applications, 6205-RSNBR Bearing is commonly found in alternators and water pumps, providing reliable radial load support. The chrome steel construction ensures durability even under continuous use.

For automation equipment like robotic arms, 6205-RSNBR Bearing offers smooth operation thanks to its precision ball design. The sealed feature also extends its lifespan by preventing contamination.

In household appliances such as washing machines, 6205-RSNBR Bearing reduces noise and vibration. Its compact size and reliable performance make it a popular choice for everyday devices.
