Snap Ring Groove Ball Bearings 6205-2RSHNR/GJN

Snap Ring Groove Ball Bearings 6205-2RSHNR/GJN

The 6205-2RSHNR/GJN is a sealed, single-row ball bearing with a 25mm bore and 52mm outer diameter, made from sturdy chrome steel. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13,000 RPM.

Its snap ring groove on the outer ring keeps it securely in place, while the sealed design protects against dust and dirt. The bearing performs well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads and secure mounting are needed.

Weighing just 128g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-2RSHNR/GJN
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 57.9 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 128 g
  • Price（$） 4.03
Snap Ring Groove Ball Bearings 6205-2RSHNR/GJN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205-2RSHNR/GJN Bearing

6205-2RSHNR/GJN Bearing features a sealed design, protecting against dust and moisture for reliable operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

The snap ring groove on the outer ring simplifies installation, saving time and effort.
With a dynamic radial load capacity of 3147 lbf, it handles demanding tasks with ease.

6205-2RSHNR/GJN Bearing operates smoothly at speeds up to 13,000 rpm, balancing performance and longevity.
Its temperature range of -30°C to 120°C makes it suitable for various environments.

The sealed design reduces maintenance needs, making it a practical choice for long-term use.
Its compact size and lightweight design ensure easy integration into different systems.

Application

Industrial Uses of 6205-2RSHNR/GJN Bearing
6205-2RSHNR/GJN Bearing is commonly used in conveyor systems, where its sealed design protects against dust and debris. The snap ring feature ensures secure mounting, ideal for continuous operation in factories.

What Makes 6205-2RSHNR/GJN Bearing a Preferred Choice?
In automotive applications like electric motors, 6205-2RSHNR/GJN Bearing offers reliable radial load support. Its chrome steel construction provides durability, even in high-temperature environments.

Perfect Fit for Automation: 6205-2RSHNR/GJN Bearing
This bearing works well in robotic arms, thanks to its smooth rotation and sealed protection. The ABEC 1 tolerance ensures consistent performance in precision tasks.

Medical vs Industrial: Where 6205-2RSHNR/GJN Bearing Excels
While suitable for industrial pumps, 6205-2RSHNR/GJN Bearing also fits lab equipment due to its low maintenance needs. The sealed design keeps contaminants out in both settings.

How Does 6205-2RSHNR/GJN Bearing Support High-Speed Operations?
With a max speed of 13,000 rpm, this bearing is great for power tools and small machinery. The chrome steel cage enhances stability during rapid rotation.
