Snap Ring Groove Ball Bearings 6017-2RSNRJ

Snap Ring Groove Ball Bearings 6017-2RSNRJ

The 6017-2RSNRJ is a sealed, single-row ball bearing with an 85mm bore and 130mm outer diameter, designed for radial loads. Its compact 22mm width makes it suitable for tight spaces, while the snap ring groove ensures secure fitting.

This bearing handles radial loads up to 11128 lbf and operates smoothly at speeds up to 5000 RPM. The chrome steel construction offers durability, and the sealed design keeps contaminants out for longer service life.

With a temperature range of -30°C to 120°C, it works well in various environments. The snap ring feature simplifies installation, making it ideal for applications like electric motors or pumps where secure mounting is needed.

Weighing 899g, it’s a sturdy choice for industrial use. Compliant with RoHS and REACH standards, it’s also interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6017-2RSNRJ
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 22 mm
  • Width Tolerance -0.200mm to 0
  • Outside Diameter Of Snap Ring 139.7 mm
  • Width Of Snap Ring 2.82 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 11128 lbf
  • Static Radial Load 9689 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 5000 rpm
  • Weight 899 g
  • Price（$） 46.4
Snap Ring Groove Ball Bearings 6017-2RSNRJ dimension drawing
Download DWG Download PDF

Features

Why Choose 6017-2RSNRJ Bearing for Precision Tasks?

6017-2RSNRJ Bearing features a sealed design, protecting against dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

The snap ring groove on the outer ring provides secure fitting, reducing the risk of misalignment.
With a dynamic radial load capacity of 11128 lbf, it handles demanding tasks with ease.

6017-2RSNRJ Bearing operates smoothly at speeds up to 5,000 rpm, balancing speed and reliability.
Its temperature range of -30°C to 120°C makes it suitable for various industrial environments.

Application

Ideal for Precision: 6017-2RSNRJ Bearing
The 6017-2RSNRJ Bearing is commonly used in industrial machinery, such as conveyor systems and pumps, where its sealed design helps keep contaminants out. Its snap ring feature ensures secure mounting, making it a reliable choice for high-vibration environments.

In automotive applications, 6017-2RSNRJ Bearing fits well in gearboxes and wheel hubs, providing smooth radial load support. The chrome steel construction offers durability, even under constant use in vehicles.

For automation equipment, 6017-2RSNRJ Bearing’s sealed and snap ring design makes it suitable for robotic arms and assembly lines. Its ABEC 1 tolerance ensures consistent performance in precision-driven tasks.

In household appliances like washing machines, 6017-2RSNRJ Bearing’s robust build helps handle repetitive motion with minimal maintenance. The sealed design also protects against dust and moisture, extending its lifespan.
