Snap Ring Groove Ball Bearings 6011-2RSNRJ

The 6011-2RSNRJ is a sealed, single-row ball bearing with a 55mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6362 lbf and operates smoothly at speeds up to 7500 RPM.

Its snap ring groove on the outer ring ensures secure fitting, while the sealed design keeps contaminants out for longer life. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads and secure mounting are key.

Weighing 373g, it offers a robust yet lightweight solution. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6011-2RSNRJ
Brand TFL
Interchangeable SKF
Bore Dia 55 mm
Bore Dia Tolerance -0.015mm to 0
Outer Dia 90 mm
Outer Dia Tolerance -0.015mm to 0
Width 18 mm
Width Tolerance -0.150mm to 0
Outside Diameter Of Snap Ring 96.5 mm
Width Of Snap Ring 2.46 mm
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Sealed
Locating Feature Bearing Outer Ring Snap Ring (fitted)
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
Dynamic Radial Load 6362 lbf
Static Radial Load 4766 lbf
Temperature Range -30°to 120 °C
ROHS Compliant
REACH Compliant
Max Speed 7500 rpm
Weight 373 g
Price（$） 16.53

Snap Ring Groove Ball Bearings 6011-2RSNRJ dimension drawing

Download DWG Download PDF

Features

Why Choose 6011-2RSNRJ Bearing for Precision Tasks?

6011-2RSNRJ Bearing features a sealed design, protecting it from dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

With a dynamic radial load capacity of 6362 lbf, it handles demanding conditions reliably.
The snap ring groove on the outer ring simplifies installation and enhances stability.

Operating at speeds up to 7,500 rpm, it balances efficiency and longevity.
Its temperature range of -30°C to 120°C makes it suitable for varied environments.

Application

Industrial Uses of 6011-2RSNRJ Bearing
6011-2RSNRJ Bearing is commonly used in conveyor systems, where its sealed design keeps out dust and debris. The snap ring feature ensures secure mounting, reducing maintenance downtime.

Where Is 6011-2RSNRJ Bearing Used?
In automotive applications, 6011-2RSNRJ Bearing fits well in electric motors and gearboxes due to its radial load capacity. The chrome steel construction offers durability in high-speed conditions.

Perfect Fit for Automation: 6011-2RSNRJ Bearing
For robotic arms, 6011-2RSNRJ Bearing provides smooth rotation with its sealed and snap ring design. Its compact size makes it ideal for precision movements in automated systems.

Light-Duty vs Heavy-Duty: Best Uses for 6011-2RSNRJ Bearing
In light-duty fans, 6011-2RSNRJ Bearing ensures quiet operation, while in heavy-duty machinery, it handles radial loads reliably. The temperature range suits both indoor and outdoor applications.
