Snap Ring Groove Ball Bearings 6007-2RS1NR (CN)

Snap Ring Groove Ball Bearings 6007-2RS1NR (CN)

The 6007-2RS1NR (CN) is a sealed snap ring groove ball bearing with a 35mm bore and 62mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 3574 lbf and operates smoothly at speeds up to 11000 RPM.

Its sealed design keeps out dust and moisture, while the snap ring on the outer ring ensures secure fitting. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing just 155g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6007-2RS1NR (CN)
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 14 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 67.7 mm
  • Width Of Snap Ring 1.7 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 3574 lbf
  • Static Radial Load 2316 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 155 g
  • Price（$） 9.63
Snap Ring Groove Ball Bearings 6007-2RS1NR (CN) dimension drawing
Download DWG Download PDF

Features

Performance Features of 6007-2RS1NR (CN) Bearing

6007-2RS1NR (CN) Bearing is designed with a snap ring groove for secure outer ring mounting, ensuring stability in radial load applications.
Its sealed construction protects against contaminants, making it suitable for various environments.

The chrome steel rings and balls provide durability, while the C0 radial clearance ensures smooth operation.
With a dynamic radial load capacity of 3574 lbf, it handles demanding conditions reliably.

6007-2RS1NR (CN) Bearing operates at speeds up to 11,000 rpm, balancing performance and longevity.
Its temperature range of -30° to 120°C makes it versatile for different working conditions.

Application

Common Applications of 6007-2RS1NR (CN) Bearing
6007-2RS1NR (CN) Bearing is widely used in industrial machinery, such as conveyor systems and electric motors, where its sealed design protects against dust and debris. The snap ring feature ensures secure mounting, making it ideal for high-vibration environments.

In automotive applications, 6007-2RS1NR (CN) Bearing is often found in wheel hubs and transmissions, providing reliable radial load support. Its chrome steel construction offers durability, even under frequent use.

For automation equipment, 6007-2RS1NR (CN) Bearing is a popular choice in robotic arms and assembly lines, thanks to its smooth operation and low maintenance requirements. The ABEC 1 tolerance ensures consistent performance in precision tasks.

In household appliances like washing machines, 6007-2RS1NR (CN) Bearing helps reduce noise and vibration, enhancing user comfort. The sealed design also extends its lifespan in humid or dusty conditions.
