Snap Ring Groove Ball Bearings 6002-2RS1NR/C3

Snap Ring Groove Ball Bearings 6002-2RS1NR/C3

The 6002-2RS1NR/C3 is a compact snap ring groove ball bearing, measuring 15mm in bore and 32mm in outer diameter, with a width of 9mm. Made from chrome steel, it offers reliable performance for radial loads up to 1259 lbf.

Its sealed design keeps dirt out and grease in, while the snap ring ensures a secure fit. The bearing can handle speeds up to 23,000 RPM and operates in temperatures from -30°C to 120°C.

With a C3 radial clearance, it provides smooth rotation under varying conditions. Ideal for small machinery or electric motors where space is limited.

Weighing just 30g, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s a safe choice for various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6002-2RS1NR/C3
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 15 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 36.7 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1259 lbf
  • Static Radial Load 641 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 23000 rpm
  • Weight 30 g
  • Price（$） 5.79
Snap Ring Groove Ball Bearings 6002-2RS1NR/C3 dimension drawing
Download DWG Download PDF

Features

How Does 6002-2RS1NR/C3 Bearing Reduce Friction?

6002-2RS1NR/C3 Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its sealed design keeps contaminants out, maintaining consistent performance over time.
The snap ring groove on the outer ring provides secure fitting, reducing vibration and wear.
With a maximum speed of 23,000 rpm, it delivers reliable efficiency in various applications.

Application

Common Applications of 6002-2RS1NR/C3 Bearing
6002-2RS1NR/C3 Bearing is widely used in industrial machinery, especially in electric motors and pumps where radial load support is needed. Its sealed design helps keep contaminants out, extending the bearing’s lifespan in dusty environments.
In automotive applications, 6002-2RS1NR/C3 Bearing fits well in alternators and small gearboxes, providing smooth rotation under moderate loads. The snap ring feature ensures secure mounting, reducing the risk of displacement during operation.
For home appliances like washing machines, 6002-2RS1NR/C3 Bearing offers quiet and reliable performance. The chrome steel construction ensures durability, even with frequent use.

Where Is 6002-2RS1NR/C3 Bearing Used?
You’ll often find 6002-2RS1NR/C3 Bearing in conveyor systems, where its sealed design protects against debris. The C3 clearance allows for slight thermal expansion, making it suitable for varying temperatures.
In small robotics, 6002-2RS1NR/C3 Bearing provides precise movement in joints and wheels. The snap ring makes installation straightforward, saving time during assembly.

Optimized for Performance: 6002-2RS1NR/C3 Bearing
6002-2RS1NR/C3 Bearing works well in office equipment like printers, where low noise and smooth operation are key. The sealed design also prevents lubricant leakage, keeping mechanisms clean.
For light industrial tools, 6002-2RS1NR/C3 Bearing handles moderate speeds efficiently. Its compact size and snap ring feature make it a versatile choice for tight spaces.

Automotive vs Industrial: Applications of 6002-2RS1NR/C3 Bearing
In cars, 6002-2RS1NR/C3 Bearing is often used in cooling fans, ensuring reliable performance under constant use. The sealed construction helps it withstand under-hood conditions.
For factory equipment, 6002-2RS1NR/C3 Bearing supports rotating parts in packaging machines. Its durability and easy maintenance make it a practical option for high-use settings.
