SKF INSOCOAT Cylindrical Roller Bearings NU 210 ECM/C3VL0241

SKF INSOCOAT Cylindrical Roller Bearings NU 210 ECM/C3VL0241

This SKF INSOCOAT cylindrical roller bearing measures 50mm by 90mm by 20mm, with a robust construction and an insulating coating on its outer ring.
It handles dynamic loads up to 280 kN and can spin at speeds reaching 5300 RPM, providing reliable performance under stress.
The insulation protects against electrical currents, with a breakdown voltage from 1000 to 3000 VDC, while the brass cage adds durability.
Suitable for electric motors or industrial machinery where electrical insulation is needed, it’s compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NU 210 ECM/C3VL0241
  • Product Category INSOCOAT Cylindrical Roller Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 50.0 mm
  • Outside Diameter 90.0 mm
  • Width 20.0 mm
  • Net Weight 0.48 kg
  • Basic Dynamic Load Rating 280.0 kN
  • Basic Static Load Rating 265.0 kN
  • Reference Speed 5300.0r/min
  • Breakdown Voltage (DC) 1000 VDC to 3000 VDC
  • Layer Thic kNess 500 µm
  • Electrical Resistance Min. 50MΩ
  • Cage Material Machined brass
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Cylindrical Roller Bearings NU 210 ECM/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Is NU 210 ECM/C3VL0241 Bearing Engineered for Reliability?

NU 210 ECM/C3VL0241 Bearing features an insulating coating on its outer ring, protecting against electrical damage.
This coating offers a breakdown voltage of 1000-3000 VDC, ensuring safe operation in electrically hazardous environments.
The machined brass cage maintains roller alignment, reducing friction and wear.
With a basic dynamic load rating of 280 kN, it handles heavy radial loads reliably.

Application

How Does NU 210 ECM/C3VL0241 Bearing Improve Performance?
NU 210 ECM/C3VL0241 Bearing works well in industrial machinery like large pumps and conveyor systems, where its cylindrical roller design handles heavy radial loads smoothly.
The insulation coating helps prevent electrical damage from stray currents, which is particularly useful in motor applications.
In automotive electric motors, NU 210 ECM/C3VL0241 Bearing supports reliable operation with its brass cage maintaining stability at high speeds.
Its C3 clearance allows for thermal expansion, making it suitable for environments with temperature variations.
For medical imaging devices, NU 210 ECM/C3VL0241 Bearing’s consistent performance ensures precision in moving parts.
The coating provides extra protection in humid conditions, extending service life in demanding medical settings.
