SKF INSOCOAT Bearings 6338M/C3VL0241

SKF INSOCOAT Bearings 6338M/C3VL0241

The SKF INSOCOAT bearing 6338M/C3VL0241 is a robust unit with a 190mm bore and 400mm outer diameter, designed for heavy-duty applications. Its insulation coating on the outer ring prevents electrical damage, making it ideal for electric motors.

With a dynamic load rating of 380kN and a static load rating of 455kN, it handles high loads efficiently. The brass cage ensures smooth operation at speeds up to 2850 r/min, even in demanding conditions.

The C3 radial clearance allows for thermal expansion, while the 500µm insulation layer offers reliable protection against electrical currents. Weighing 48.8kg, it’s built for durability in industrial settings.

Compliant with ROHS standards, this bearing suits environments where electrical insulation and high performance are crucial, such as wind turbines or large generators.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6338M/C3VL0241
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 190.0 mm
  • Outside Diameter 400.0 mm
  • Width 78.0 mm
  • Net Weight 48.8 kg
  • Basic Dynamic Load Rating 380.0 kN
  • Basic Static Load Rating 455.0 kN
  • Reference Speed 2850 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Brass cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6338M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Is 6338M/C3VL0241 Bearing Engineered for Reliability?

6338M/C3VL0241 Bearing features an insulation coating on the outer ring, protecting against electrical currents and extending its lifespan.
The brass cage ensures smooth operation, even at high speeds up to 2850 r/min.

With a basic dynamic load rating of 380.0 kN, 6338M/C3VL0241 Bearing handles heavy loads reliably.
Its C3 radial internal clearance allows for thermal expansion, making it suitable for various industrial applications.

The insulation coating provides a breakdown voltage of ≤3000 V, ensuring safety in electrically demanding environments.
6338M/C3VL0241 Bearing’s robust design and materials make it a dependable choice for long-term use.

Application

Industrial Uses of 6338M/C3VL0241 Bearing
6338M/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing and extends service life. The brass cage ensures smooth operation even under high rotational speeds.

What Makes 6338M/C3VL0241 Bearing a Preferred Choice?
With a breakdown voltage of up to 3000 V, 6338M/C3VL0241 Bearing is ideal for applications in wind turbines and industrial drives. Its C3 radial clearance allows for thermal expansion in demanding environments.

Perfect Fit for Automation: 6338M/C3VL0241 Bearing
In automated production lines, 6338M/C3VL0241 Bearing handles heavy loads while maintaining precision. The insulation coating also reduces downtime caused by electrical damage.

Medical vs Industrial: Where 6338M/C3VL0241 Bearing Excels
While not typically used in medical devices, 6338M/C3VL0241 Bearing shines in industrial settings like steel mills. Its robust design and high dynamic load rating make it reliable for heavy machinery.

Essential Roles of 6338M/C3VL0241 Bearing
6338M/C3VL0241 Bearing supports large-scale equipment such as pumps and compressors, where its static load capacity ensures stability. The coating also resists wear in harsh operating conditions.
