SKF INSOCOAT Bearings 6324/C3VL2071

SKF INSOCOAT Bearings 6324/C3VL2071

The SKF INSOCOAT bearing 6324/C3VL2071 is a robust unit measuring 120mm by 260mm by 55mm, with a durable inner ring insulation coating. It handles dynamic loads up to 216 kN and spins smoothly at speeds up to 5600 RPM.

Its VL2071 coating provides insulation with a breakdown voltage of up to 3000V, ideal for preventing electrical damage. The sheet metal cage ensures reliable performance under heavy loads.

With a C3 radial clearance, it accommodates thermal expansion in demanding conditions. Suitable for electric motors or generators where electrical insulation is crucial.

Weighing 12.2kg, it’s built for industrial use while complying with RoHS standards. The 200 MΩ resistance and 500µm coating thickness offer long-term protection against current leakage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6324/C3VL2071
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Inner ring insulation coating
  • Coating Suffix VL2071
  • Manufacturers SKF
  • Bore Diameter 120.0 mm
  • Outside Diameter 260.0 mm
  • Width 55.0 mm
  • Net Weight 12.2kg
  • Basic Dynamic Load Rating 216.0 kN
  • Basic Static Load Rating 186.0 kN
  • Reference Speed 5600.0 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Sheet metal
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6324/C3VL2071 dimension drawing
Download DWG Download PDF

Features

Why Choose 6324/C3VL2071 Bearing for Precision Tasks?

6324/C3VL2071 Bearing features an inner ring insulation coating, making it ideal for electrical applications.
The VL2071 coating provides a breakdown voltage of up to 3000 V, ensuring reliable insulation.

With a dynamic load rating of 216 kN, 6324/C3VL2071 Bearing handles heavy loads efficiently.
Its C3 radial clearance allows for thermal expansion, maintaining performance in varying conditions.

The sheet metal cage ensures smooth operation at high speeds, up to 5600 r/min.
6324/C3VL2071 Bearing’s electrical resistance of 200 MΩ prevents current leakage.

Application

Industrial Uses of 6324/C3VL2071 Bearing
This bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage from stray currents. The C3 clearance ensures reliable performance even under thermal expansion.

Where Is 6324/C3VL2071 Bearing Used?
You’ll often find it in wind turbines and industrial pumps, handling high dynamic loads with ease. The sheet metal cage adds durability, making it suitable for long-term use in harsh environments.

Built for Heavy-Duty Use: 6324/C3VL2071 Bearing
In conveyor systems and heavy machinery, this bearing’s high load capacity and insulation make it a dependable choice. Its breakdown voltage rating ensures safety in electrically noisy settings.

Automotive vs Aerospace: Applications of 6324/C3VL2071 Bearing
While it’s used in automotive alternators for its insulation, it also suits aerospace applications where electrical resistance matters. The 260mm outer diameter fits various industrial and transport needs.

Perfect Fit for Automation: 6324/C3VL2071 Bearing
In robotic arms and automated production lines, this bearing’s precision and insulation reduce downtime. The 120mm bore diameter works well with standard motor shafts.
