SKF INSOCOAT Bearings 6320M/C3VL0241

SKF INSOCOAT Bearings 6320M/C3VL0241

The SKF INSOCOAT bearing 6320M/C3VL0241 measures 100mm in bore diameter and 215mm outside, with a width of 47mm. Its outer ring features a 500µm insulating coating, providing electrical resistance up to 200 MΩ.

This bearing handles dynamic loads up to 182 kN and spins smoothly at reference speeds of 6700 RPM. The brass cage ensures durability, while the C3 radial clearance allows for thermal expansion.

The insulation coating prevents electrical arcing, making it ideal for electric motors or generators. It’s also RoHS compliant for safe use in various industries.

Weighing 8.02kg, it’s a robust choice for heavy-duty applications where electrical insulation is crucial. The VL0241 coating suffix ensures consistent performance under high-voltage conditions.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6320M/C3VL0241
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 100.0 mm
  • Outside Diameter 215.0 mm
  • Width 47.0 mm
  • Net Weight 8.02kg
  • Basic Dynamic Load Rating 182.0 kN
  • Basic Static Load Rating 140.0 kN
  • Reference Speed 6700.0 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Brass cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6320M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

How Is 6320M/C3VL0241 Bearing Engineered for Reliability?

6320M/C3VL0241 Bearing features an insulating coating on the outer ring, protecting against electrical damage.
Its brass cage ensures smooth operation and reduces friction, even at high speeds up to 6,700 r/min.

The bearing’s basic dynamic load rating of 182 kN makes it suitable for heavy-duty applications.
With a breakdown voltage of ≤3000 V, it prevents current-induced wear, enhancing longevity.

6320M/C3VL0241 Bearing’s C3 radial internal clearance allows for thermal expansion in demanding conditions.
The insulation layer thickness of 500 µm ensures reliable performance in electrically harsh environments.

Application

Industrial Uses of 6320M/C3VL0241 Bearing
The 6320M/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical damage from stray currents. Its brass cage ensures smooth operation even under high-speed conditions.

What Makes 6320M/C3VL0241 Bearing a Preferred Choice?
With a high dynamic load rating, 6320M/C3VL0241 Bearing handles heavy industrial loads effortlessly, making it ideal for compressors and pumps. The C3 radial clearance allows for thermal expansion in demanding environments.

Perfect Fit for Automation: 6320M/C3VL0241 Bearing
In robotic arms and CNC machines, 6320M/C3VL0241 Bearing offers reliable performance thanks to its stable electrical resistance. The 500 µm insulation layer ensures long-term durability in electrically noisy settings.

Automotive vs Aerospace: Applications of 6320M/C3VL0241 Bearing
While 6320M/C3VL0241 Bearing suits hybrid vehicle drivetrains due to its insulation, it also excels in aerospace actuators where precision is key. The 215 mm outer diameter provides ample support for radial loads.

Essential Roles of 6320M/C3VL0241 Bearing
For wind turbine generators, 6320M/C3VL0241 Bearing’s breakdown voltage rating safeguards against electrical arcing. Its 47 mm width balances compact design with robust load capacity.
