Single Row Deep Groove Ball Bearings With Filling Slots 212-2Z

Single Row Deep Groove Ball Bearings With Filling Slots 212-2Z

The 212-2Z is a single-row deep groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 12612 lbf and operates smoothly at speeds up to 5400 RPM.

Shielded on both sides, it keeps grease in and dirt out, while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 120°C.

Its filling slots make regreasing straightforward, extending service life. Compatible with SKF models, it’s a practical choice for replacements.

Weighing 0.85kg, it’s suited for industrial machinery, pumps, or electric motors where radial load handling is key. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 212-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.15mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Grade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 12612 lbf
  • Static Radial Load 11240 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5400 rpm
  • Weight 0.85 kg
  • Price（$） 21.88
Single Row Deep Groove Ball Bearings With Filling Slots 212-2Z dimension drawing
Download DWG Download PDF

Features

How Does 212-2Z Bearing Reduce Friction?

212-2Z Bearing features a deep groove design with filling slots, ensuring smooth radial load distribution.
The chrome steel rings and balls work together to minimise friction during operation.

Its nylon cage helps maintain ball alignment, reducing wear and enhancing efficiency.
With a maximum speed of 5,400 rpm, it offers reliable performance in various applications.

The shielded design protects against contaminants, extending the bearing’s service life.
Grease lubrication further reduces friction, ensuring quiet and smooth operation.

Application

Industrial Uses of 212-2Z Bearing
212-2Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The deep groove construction handles radial loads efficiently, making it suitable for continuous operation.

In automotive applications, 212-2Z Bearing fits well in wheel hubs and alternators, providing reliable performance under varying speeds. Its nylon cage reduces friction, which can help improve fuel efficiency over time.

For automation systems, 212-2Z Bearing works smoothly in conveyor belts and robotic arms, thanks to its balanced load capacity. The grease lubrication ensures quiet operation, even in high-speed scenarios.

Around the home, 212-2Z Bearing can be found in appliances like washing machines, where durability matters. Its chrome steel rings resist wear, extending the life of everyday devices.
