Single Row Deep Groove Ball Bearings 6412

Single Row Deep Groove Ball Bearings 6412

The 6412 is a single-row deep groove ball bearing with a 60mm bore and 150mm outer diameter, crafted from sturdy chrome steel for lasting performance. It handles radial loads up to 24279 lbf and operates smoothly at speeds up to 4800 RPM.

Its open design simplifies lubrication, while the stainless steel cage ensures durability under heavy use. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. It’s well-suited for applications like electric motors or conveyor systems where radial loads are common.

Weighing 2750g, it’s a robust choice for industrial settings. Compliant with RoHS and REACH standards, it meets safety and environmental requirements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6412
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 35 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 24279 lbf
  • Static Radial Load 15624 lbf
  • Max Speed 4800 rpm
  • Weight 2750 g
  • price（$） 56.88
Single Row Deep Groove Ball Bearings 6412 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6412 Bearing

6412 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 24,279 lbf, ensuring reliable performance in various applications.

The stainless steel cage maintains ball alignment, reducing friction and extending service life.
With a maximum speed of 4,800 rpm, it balances durability and efficiency for smooth operation.

Designed for radial loads, 6412 Bearing operates efficiently in temperatures from -30° to 110°C.
Its open seal type allows for easy lubrication, ensuring consistent performance over time.

Application

Industrial Uses of 6412 Bearing
The 6412 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads effectively. Its open seal type allows for easy lubrication, extending service life in demanding conditions.

What Makes 6412 Bearing a Preferred Choice?
In automotive applications, 6412 Bearing fits well in wheel hubs and transmissions due to its robust chrome steel construction. The ABEC-1 tolerance ensures reliable performance without unnecessary complexity.

Perfect Fit for Automation: 6412 Bearing
For automated systems, 6412 Bearing works smoothly in conveyor belts and robotic arms, thanks to its balanced load capacity. The stainless steel cage adds durability, making it suitable for continuous operation.

Medical vs Industrial: Where 6412 Bearing Excels
While 6412 Bearing isn’t typically used in medical devices, it shines in industrial settings like gearboxes and compressors. Its metric sizing and compliance with ROHS standards make it versatile for global applications.
