Single Row Deep Groove Ball Bearings 6320-2Z

Single Row Deep Groove Ball Bearings 6320-2Z

The 6320-2Z is a single-row deep groove ball bearing with a 100mm bore and 215mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 39117 lbf and runs smoothly at speeds up to 3400 RPM.

Shielded on both sides, it keeps grease in and dirt out, making it low-maintenance. The stainless steel cage adds durability, while the P6 tolerance ensures precise performance.

Suitable for temperatures from -30°C to 120°C, this bearing is ideal for industrial machinery or electric motors. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 7.3kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6320-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 100 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 215 mm
  • Outer Dia Tolerance -0.020mm to 0
  • Width 47 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 39117 lbf
  • Static Radial Load 31473 lbf
  • Max Speed 3400 rpm
  • Weight 7.3 kg
  • price（$） 112.86
Single Row Deep Groove Ball Bearings 6320-2Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 6320-2Z Bearing

6320-2Z Bearing is designed for radial loads, with a dynamic radial load capacity of 39117 lbf for reliable performance.
Its chrome steel rings and balls provide durability, while the stainless steel cage ensures smooth operation.

The shielded design of 6320-2Z Bearing protects against contaminants, extending its service life.
With a maximum speed of 3,400 rpm, it balances efficiency and durability in various applications.

6320-2Z Bearing operates in temperatures from -30° to 120°C, making it suitable for diverse environments.
Its grease lubrication reduces maintenance needs, ensuring long-term reliability.

Application

Industrial Uses of 6320-2Z Bearing
The 6320-2Z Bearing is commonly used in heavy machinery like pumps and electric motors, where its shielded design helps keep contaminants out. Its high dynamic radial load capacity makes it reliable for continuous operation in demanding environments.

Where Is 6320-2Z Bearing Used?
You’ll often find the 6320-2Z Bearing in conveyor systems and gearboxes, thanks to its sturdy chrome steel construction. The grease lubrication ensures smooth performance even under high radial loads.

Built for Heavy-Duty Use: 6320-2Z Bearing
The 6320-2Z Bearing handles radial loads effortlessly in applications like industrial fans and compressors. Its stainless steel cage adds durability, making it a solid choice for long-term use.

Automotive vs Industrial: Applications of 6320-2Z Bearing
In automotive systems, the 6320-2Z Bearing supports components like wheel hubs, while in industrial settings, it’s ideal for machinery requiring consistent radial load support. Its metric sizing ensures broad compatibility.

Perfect Fit for Automation: 6320-2Z Bearing
The 6320-2Z Bearing works well in automated systems like robotic arms, where precision and reliability are key. Its shielded seals help maintain performance in dusty or humid conditions.
