Single Row Deep Groove Ball Bearings 6318-2RSJEM

Single Row Deep Groove Ball Bearings 6318-2RSJEM

The 6318-2RSJEM is a sealed single row deep groove ball bearing, measuring 90mm in bore and 190mm in outer diameter. Made from durable chrome steel, it handles radial loads up to 32148 lbf and operates smoothly at speeds up to 3600 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance for long-term use. The bearing works well in temperatures from -30°C to 120°C, suitable for various environments.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for industrial machinery, pumps, or electric motors where radial loads are common.

Weighing 4920g, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6318-2RSJEM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 90 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 190 mm
  • Outer Dia Tolerance -0.03mm to 0
  • Width 43 mm
  • Width Tolerance -0.200mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 32148 lbf
  • Static Radial Load 24055 lbf
  • Max Speed 3600 rpm
  • Weight 4920 g
  • price（$） 86.4
Single Row Deep Groove Ball Bearings 6318-2RSJEM dimension drawing
Download DWG Download PDF

Features

Performance Features of 6318-2RSJEM Bearing

6318-2RSJEM Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 32,148 lbf, ensuring reliable performance in various applications.

The sealed design of 6318-2RSJEM Bearing protects against dust and moisture, extending its service life.
With a maximum speed of 3,600 rpm, it balances durability and efficiency for industrial use.

6318-2RSJEM Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its precision construction meets ABEC 1 and ISO P0 standards for consistent performance.

Application

Industrial Uses of 6318-2RSJEM Bearing
6318-2RSJEM Bearing is commonly used in heavy machinery like conveyor systems and industrial fans, where its sealed design helps keep out dust and debris. The chrome steel construction ensures it can handle significant radial loads without wearing out quickly.

Where Is 6318-2RSJEM Bearing Used?
You’ll often find 6318-2RSJEM Bearing in automotive applications such as wheel hubs and transmissions, thanks to its durability and smooth operation. Its metric sizing makes it a reliable choice for both European and Asian vehicle models.

Perfect Fit for Automation: 6318-2RSJEM Bearing
In automated production lines, 6318-2RSJEM Bearing provides reliable performance in robotic arms and assembly equipment. The sealed design reduces maintenance needs, making it ideal for high-use environments.

Medical vs Industrial: Where 6318-2RSJEM Bearing Excels
While 6318-2RSJEM Bearing is robust enough for industrial gearboxes, its precision also suits medical devices like imaging equipment. The consistent performance and long lifespan make it a versatile choice across sectors.

Consumer Electronics and More: 6318-2RSJEM Bearing
Even in household appliances like washing machines, 6318-2RSJEM Bearing ensures quiet and efficient operation. Its sealed design is particularly useful in environments where moisture and dust are common.
