Single Row Deep Groove Ball Bearings 6317-2ZJEM

Single Row Deep Groove Ball Bearings 6317-2ZJEM

The 6317-2ZJEM is a single-row deep groove ball bearing with an 85mm bore and 180mm outer diameter, crafted from sturdy chrome steel for lasting performance. Its shielded design keeps out dust and debris while maintaining smooth operation.

This model handles radial loads up to 21762 lbf and runs comfortably at speeds up to 3800 RPM. The chrome steel cage adds durability, making it suitable for continuous use in various conditions.

With a compact width of 41mm, it fits neatly into machinery where space matters. The bearing operates reliably in temperatures from -30°C to 120°C.

Ideal for industrial equipment or automotive applications requiring consistent radial load support. Compliant with RoHS and REACH standards, it’s a dependable choice for replacements, especially where SKF compatibility is needed.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6317-2ZJEM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 41 mm
  • Width Tolerance -0.200mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 299 lbf
  • Static Radial Load 21762 lbf
  • Max Speed 3800 rpm
  • Weight 4220 g
  • price（$） 73.107
Single Row Deep Groove Ball Bearings 6317-2ZJEM dimension drawing
Download DWG Download PDF

Features

Performance Features of 6317-2ZJEM Bearing

6317-2ZJEM Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 299 lbf, making it suitable for various industrial applications.
The shielded design protects against contaminants, ensuring smooth operation in challenging environments.
With a maximum speed of 3,800 rpm, it balances performance and durability.

How Is 6317-2ZJEM Bearing Engineered for Reliability?

6317-2ZJEM Bearing features a single-row deep groove design, providing reliable radial load support.
The chrome steel construction enhances durability, even in demanding operating conditions.
Its shielded seals help keep out dust and debris, reducing maintenance needs.
With a temperature range of -30° to 120°C, it performs well in varied environments.

Designed for Durability: 6317-2ZJEM Bearing

6317-2ZJEM Bearing’s chrome steel cage ensures stable ball alignment, minimising wear over time.
The ABEC 1 tolerance class guarantees consistent performance for general applications.
Its static radial load capacity of 21,762 lbf makes it robust for heavy-duty use.
The shielded design offers added protection without compromising speed capabilities.

Application

Industrial Uses of 6317-2ZJEM Bearing
6317-2ZJEM Bearing works well in conveyor systems and industrial gearboxes, handling radial loads with ease. Its shielded design keeps contaminants out, extending service life in dusty environments.

What Makes 6317-2ZJEM Bearing a Preferred Choice?
In automotive applications like electric motors, 6317-2ZJEM Bearing offers reliable performance due to its chrome steel construction. The ABEC 1 tolerance ensures smooth operation without unnecessary friction.

Built for Heavy-Duty Use: 6317-2ZJEM Bearing
This bearing suits agricultural machinery, where its robust design handles uneven loads. The wide temperature range makes it adaptable to outdoor conditions.

Automotive vs Industrial: Applications of 6317-2ZJEM Bearing
While commonly used in truck wheel hubs, 6317-2ZJEM Bearing also fits pumps and compressors. Its metric sizing simplifies replacements across different equipment types.
