Single Row Deep Groove Ball Bearings 6317-2Z

Single Row Deep Groove Ball Bearings 6317-2Z

The 6317-2Z is a single-row deep groove ball bearing with an 85mm bore and 180mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 31473 lbf and operates smoothly at speeds up to 4000 RPM.

Shielded on both sides, it keeps grease in and dirt out, making it low-maintenance. The stainless steel cage adds durability, ensuring reliable performance even under heavy loads.

With a temperature range of -30°C to 120°C, it’s suitable for various environments. Its P6 tolerance class ensures precision, while the CN radial clearance offers balanced operation.

Ideal for industrial machinery, pumps, or electric motors, this bearing is interchangeable with SKF models. Weighing 4.4kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6317-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 41 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 31473 lbf
  • Static Radial Load 21694 lbf
  • Max Speed 4000 rpm
  • Weight 4.4 kg
  • price（$） 67.86
Single Row Deep Groove Ball Bearings 6317-2Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 6317-2Z Bearing

6317-2Z Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 31,473 lbf.
Its shielded design protects against contaminants while maintaining smooth operation.

The stainless steel cage ensures proper ball alignment, reducing friction and wear.
With a maximum speed of 4,000 rpm, it delivers reliable performance in various applications.

6317-2Z Bearing operates efficiently in temperatures ranging from -30° to 120°C.
Its grease lubrication reduces maintenance needs, making it a practical choice for long-term use.

The P6 tolerance class ensures precision and consistency in performance.
This bearing is ideal for applications requiring durability and smooth radial load handling.

Application

Industrial Uses of 6317-2Z Bearing
6317-2Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

Where Is 6317-2Z Bearing Used?
In automotive applications, 6317-2Z Bearing can be found in wheel hubs and transmissions, providing reliable radial load support. Its grease lubrication helps maintain smooth operation over long periods.

Built for Heavy-Duty Use: 6317-2Z Bearing
For automation systems, 6317-2Z Bearing works well in conveyor belts and robotic arms, thanks to its high dynamic radial load capacity. The stainless steel cage adds extra resistance to wear and tear.

Light-Duty vs Heavy-Duty: Best Uses for 6317-2Z Bearing
In consumer electronics like washing machines, 6317-2Z Bearing offers quiet and efficient performance. Its metric sizing makes it a versatile choice for various household appliances.
