Single Row Deep Groove Ball Bearings 6313

Brand: TFL Bearing Interchangeable: SKF 6313 65 mm × 140 mm × 33 mm Metric Open
Part number: 6313
Single Row Deep Groove Ball Bearings 6313
In Stock
US$36.00 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia65 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia140 mm
Outer Dia Tolerance-0.018mm to 0
Width33 mm
Width Tolerance-0.150mm to 0
Performance
Temperature Range-30° to 110 °C
Dynamic Radial Load2,084 lbf
Static Radial Load13,466 lbf
Max Speed4,800 rpm
Characteristics
System of MeasurementMetric
For Load DirectionRadial
ConstructionSingle Row
Bearing TypeBall
Seal TypeOpen
Tolerance ClassABEC-1
Radial Clearance Trade NoCN
LubricationRequired
Weight2,080 g
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialStainless Steel
Compliance
REACHCompliant
Dimension drawing · click to enlarge

Description

The 6313 is a single-row deep groove ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 2084 lbf and operates smoothly at speeds up to 4800 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing works efficiently in temperatures ranging from -30°C to 110°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 2080g, it provides a solid balance of strength and manageability. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Features

Performance Features of 6313 Bearing

6313 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 2084 lbf, ensuring reliable performance in various applications.

The stainless steel cage maintains ball alignment, reducing friction and extending operational life.
With a maximum speed of 4,800 rpm, it balances efficiency and durability.

6313 Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design simplifies lubrication, making maintenance straightforward.

Application

Industrial Uses of 6313 Bearing
The 6313 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. Its open seal type allows for easy lubrication, extending service life in demanding conditions.

In automotive applications, 6313 Bearing fits well in wheel hubs and transmissions, providing reliable performance under varying speeds. The chrome steel construction ensures durability, even in high-temperature environments.

For automation systems, 6313 Bearing supports robotic arms and conveyor belts with smooth operation. Its ABEC-1 tolerance class offers a good balance of precision and cost-effectiveness for general machinery.

Where to Use 6313 Bearing
You’ll often find 6313 Bearing in household appliances like washing machines, where its static load capacity handles vibrations effectively. The stainless steel cage adds corrosion resistance, ideal for damp environments.

In agricultural equipment, 6313 Bearing withstands heavy loads in tractors and harvesters. Its metric sizing makes it compatible with a wide range of machinery, simplifying maintenance and replacements.
