Single Row Deep Groove Ball Bearings 6313/VW514

Single Row Deep Groove Ball Bearings 6313/VW514

The 6313/VW514 is a single-row deep groove ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 2084 lbf and operates smoothly at speeds reaching 4800 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. It’s well-suited for applications like electric motors or pumps where radial loads are prevalent.

Weighing 2080g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6313/VW514
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 33 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2084 lbf
  • Static Radial Load 13466 lbf
  • Max Speed 4800 rpm
  • Weight 2080 g
Single Row Deep Groove Ball Bearings 6313/VW514 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6313/VW514 Bearing

6313/VW514 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 2084 lbf, ensuring reliable performance in various applications.

The single-row deep groove design enhances stability, making it suitable for high-speed operations.
With a maximum speed of 4,800 rpm, it balances durability and efficiency effortlessly.

6313/VW514 Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its open seal type allows for easy maintenance and reduces operational costs.

Application

Industrial Uses of 6313/VW514 Bearing
6313/VW514 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending service life in demanding conditions.

In automotive applications, 6313/VW514 Bearing fits well in wheel hubs and transmission systems, providing smooth rotation under heavy loads. Its metric sizing makes it a versatile choice for various vehicle models.

For automation equipment, 6313/VW514 Bearing supports precise movement in robotic arms and conveyor belts. The chrome steel construction offers durability, even in high-speed operations.

What Makes 6313/VW514 Bearing a Preferred Choice?
6313/VW514 Bearing is a solid pick for household appliances like washing machines, thanks to its balanced load handling. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

In agricultural machinery, 6313/VW514 Bearing handles rough conditions in equipment like harvesters. Its robust design minimises downtime, making it a practical solution for farmers.
