Single Row Deep Groove Ball Bearings 6313 M/C3VL0241

The 6313 M/C3VL0241 is a single-row deep groove ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 2084 lbf and operates smoothly at speeds up to 4800 RPM.

Its open design allows for easy lubrication, while the machined metal cage ensures durability under heavy use. The bearing works efficiently in temperatures ranging from -30°C to 120°C.

With a C3 radial clearance, it accommodates slight misalignments and thermal expansion. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for industrial machinery or electric motors where radial loads are common, it weighs 2080g for its robust size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6313 M/C3VL0241
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No C3
Bore Dia 65 mm
Bore Dia Tolerance -0.015mm to 0
Outer Dia 140 mm
Outer Dia Tolerance -0.018mm to 0
Width 33 mm
Width Tolerance -0.150mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Machined metal
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 2084 lbf
Static Radial Load 13466 lbf
Max Speed 4800 rpm
Weight 2080 g
price（$） 141.471

Single Row Deep Groove Ball Bearings 6313 M/C3VL0241 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6313 M/C3VL0241 Bearing

6313 M/C3VL0241 Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 2084 lbf, making it suitable for various industrial applications.

The machined metal cage ensures precise ball alignment, enhancing durability and reducing friction.
With a maximum speed of 4,800 rpm, it delivers reliable performance under demanding conditions.

6313 M/C3VL0241 Bearing operates in temperatures from -30°C to 120°C, adapting to different environments.
Its C3 radial clearance provides flexibility, ensuring smooth operation even with thermal expansion.

The open design simplifies maintenance, while the chrome steel construction resists wear over time.
This bearing is a cost-effective choice for applications requiring consistent radial load support.

Application

Industrial Uses of 6313 M/C3VL0241 Bearing
6313 M/C3VL0241 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 6313 M/C3VL0241 Bearing fits well in wheel hubs and transmissions, providing smooth rotation under heavy loads. Its C3 clearance ensures reliable performance even with thermal expansion during long drives.

For automation systems, 6313 M/C3VL0241 Bearing supports robotic arms and conveyor belts, where precision and durability are key. The machined metal cage adds strength, making it suitable for high-speed operations.

What Makes 6313 M/C3VL0241 Bearing a Preferred Choice?
6313 M/C3VL0241 Bearing stands out in household appliances like washing machines, thanks to its chrome steel construction resisting wear over time. The metric sizing ensures compatibility with a wide range of European-designed equipment.

In agricultural machinery, 6313 M/C3VL0241 Bearing handles the rough conditions of tractors and harvesters. Its ABEC 1 tolerance balances cost and performance, making it a practical choice for farmers.
