Single Row Deep Groove Ball Bearings 6313/C5

Single Row Deep Groove Ball Bearings 6313/C5

The 6313/C5 is a single-row deep groove ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2084 lbf and operates smoothly at speeds up to 4800 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 2080g, it offers a robust build for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6313/C5
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C5
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 33 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2084 lbf
  • Static Radial Load 13466 lbf
  • Max Speed 4800 rpm
  • Weight 2080 g
Single Row Deep Groove Ball Bearings 6313/C5 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6313/C5 Bearing

6313/C5 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 2084 lbf.
Its single-row deep groove design ensures smooth operation and reliable performance in various applications.

The C5 radial clearance allows for better thermal expansion handling, making it suitable for high-speed use.
With a maximum speed of 4,800 rpm, it balances efficiency and durability.

6313/C5 Bearing operates in temperatures from -30°C to 120°C, adapting to different working conditions.
Its open seal design simplifies maintenance while maintaining performance.

The chrome steel cage keeps the balls aligned, reducing wear and extending service life.
This bearing is ideal for applications requiring consistent radial load support.

Application

Common Applications of 6313/C5 Bearing
6313/C5 Bearing is widely used in industrial machinery, such as pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 6313/C5 Bearing fits well in wheel hubs and transmissions, providing smooth rotation under heavy loads. Its metric dimensions make it a versatile choice for various vehicle models.

For automation systems, 6313/C5 Bearing supports robotic arms and conveyor belts, where precision and durability are key. The chrome steel construction ensures it can handle continuous operation without wear.

In household appliances like washing machines, 6313/C5 Bearing offers quiet and efficient performance. Its robust design makes it suitable for high-speed spinning cycles.

Medical devices such as centrifuges benefit from 6313/C5 Bearing’s consistent operation. The C5 clearance ensures minimal friction, crucial for sensitive equipment.
