Single Row Deep Groove Ball Bearings 6312/W64

Single Row Deep Groove Ball Bearings 6312/W64

The 6312/W64 is a single-row deep groove ball bearing with a 60mm bore and 130mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 18412 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective replacement option. Suitable for applications like electric motors or pumps where radial load handling is key.

Weighing 1699g, it balances strength and practicality. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6312/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 31 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 18412 lbf
  • Static Radial Load 11735 lbf
  • Max Speed 5300 rpm
  • Weight 1699 g
  • price（$） 41.481
Single Row Deep Groove Ball Bearings 6312/W64 dimension drawing
Download DWG Download PDF

Features

How Does 6312/W64 Bearing Reduce Friction?

6312/W64 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.

Its chrome steel construction ensures durability while the solid oil lubrication reduces friction effectively.

With a dynamic radial load capacity of 18,412 lbf, it handles demanding applications with ease.

The ABEC 1 tolerance class guarantees consistent performance, making it a reliable choice for various uses.

Application

Industrial Uses of 6312/W64 Bearing
6312/W64 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The solid oil lubrication reduces maintenance needs, making it ideal for continuous operation.

Where Is 6312/W64 Bearing Used?
In automotive applications, 6312/W64 Bearing fits well in wheel hubs and transmissions, thanks to its durable chrome steel construction. Its metric sizing ensures compatibility with a variety of vehicle designs.

Perfect Fit for Automation: 6312/W64 Bearing
For automation systems, 6312/W64 Bearing works smoothly in robotic arms and conveyor belts, handling moderate speeds with ease. The open design allows for easy inspection and cleaning.

Medical vs Industrial: Where 6312/W64 Bearing Excels
In medical devices, 6312/W64 Bearing offers quiet operation for equipment like centrifuges. Its temperature range suits both industrial and clinical environments.

Key Fields for 6312/W64 Bearing
Household appliances like washing machines benefit from 6312/W64 Bearing’s balanced performance. The ABEC 1 tolerance ensures smooth rotation without excessive noise.
