Single Row Deep Groove Ball Bearings 6311 TC/C782

Single Row Deep Groove Ball Bearings 6311 TC/C782

The 6311 TC/C782 is a single-row deep groove ball bearing with a 55mm bore and 120mm outer diameter, crafted from sturdy chrome steel for durability. It handles radial loads up to 16096 lbf and operates smoothly at speeds up to 5600 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures reliable performance under stress. The bearing works efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 1350g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe and dependable option for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6311 TC/C782
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 29 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 16096 lbf
  • Static Radial Load 10116 lbf
  • Max Speed 5600 rpm
  • Weight 1350 g
  • price（$） 160.227
Single Row Deep Groove Ball Bearings 6311 TC/C782 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6311 TC/C782 Bearing

6311 TC/C782 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 16096 lbf.

Its single-row deep groove design ensures smooth operation and efficient load distribution.

The open seal type allows for easy lubrication, making it suitable for various industrial applications.

With a maximum speed of 5,600 rpm, it balances performance and durability in demanding conditions.

Application

Industrial Uses of 6311 TC/C782 Bearing
The 6311 TC/C782 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 6311 TC/C782 Bearing fits well in components such as alternators and wheel hubs, providing smooth rotation under heavy loads. The chrome steel construction offers durability, even in demanding driving conditions.

For automation equipment, 6311 TC/C782 Bearing supports precise movement in robotic arms and conveyor systems. Its ISO P0 tolerance ensures consistent operation, reducing downtime in production lines.

In household appliances like washing machines, 6311 TC/C782 Bearing handles the constant motion of drums and agitators. The wide temperature range makes it adaptable to various operating environments.
