Single Row Deep Groove Ball Bearings 6309-2ZJEM

The 6309-2ZJEM is a single-row deep groove ball bearing with a 45mm bore and 100mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 11915 lbf and operates smoothly at speeds up to 6700 RPM.

Its shielded design keeps dirt out while maintaining easy access for lubrication. The chrome steel cage ensures strength and longevity, even in demanding conditions.

This bearing works well in temperatures from -30°C to 120°C, making it versatile for various environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Ideal for applications like electric motors or pumps where radial load support is needed. Weighing 811g, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6309-2ZJEM
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 45 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 100 mm
Outer Dia Tolerance -0.015mm to 0
Width 25 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 11915 lbf
Static Radial Load 7194 lbf
Max Speed 6700 rpm
Weight 811 g
price（$） 15.057

Single Row Deep Groove Ball Bearings 6309-2ZJEM dimension drawing

Download DWG Download PDF

Features

How Does 6309-2ZJEM Bearing Reduce Friction?

6309-2ZJEM Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while reducing friction during operation.

Its shielded design helps keep contaminants out, maintaining consistent performance over time.
With a dynamic radial load capacity of 11915 lbf, it handles demanding applications with ease.

The ABEC 1 tolerance class ensures reliable precision in various industrial settings.
Operating temperatures range from -30°C to 120°C, making it versatile for different environments.

Application

Common Applications of 6309-2ZJEM Bearing
In industrial settings, 6309-2ZJEM Bearing is commonly used in pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

How Does 6309-2ZJEM Bearing Improve Performance?
For automotive applications like alternators and wheel hubs, 6309-2ZJEM Bearing provides smooth rotation and reliable load handling. Its ABEC 1 tolerance makes it a cost-effective choice without compromising performance.

Built for Heavy-Duty Use: 6309-2ZJEM Bearing
In conveyor systems and agricultural machinery, 6309-2ZJEM Bearing handles radial loads with ease. The shielded seals extend its lifespan by protecting against dust and debris.

Automotive vs Industrial: Where 6309-2ZJEM Bearing Excels
While 6309-2ZJEM Bearing works well in car transmissions, it’s equally suited for factory equipment like gearboxes. Its balanced design offers versatility across different load conditions.

Perfect Fit for Automation: 6309-2ZJEM Bearing
In robotic arms and automated assembly lines, 6309-2ZJEM Bearing ensures precise movement. The metric sizing simplifies integration with European and Asian machinery standards.
