Single Row Deep Groove Ball Bearings 6309-2Z/VP1760

The 6309-2Z/VP1760 is a single row deep groove ball bearing with a 45mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 11915 lbf and operates smoothly at speeds up to 6700 RPM.

Shielded on both sides, it keeps dirt out while maintaining smooth rotation. The chrome steel cage adds durability, making it a reliable choice for various applications.

This bearing works well in temperatures from -30°C to 120°C, suitable for industrial environments. It’s interchangeable with SKF models, offering a practical replacement option.

Weighing 811g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use. Ideal for machinery requiring consistent radial load support.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6309-2Z/VP1760
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 45 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 100 mm
Outer Dia Tolerance -0.015mm to 0
Width 25 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 11915 lbf
Static Radial Load 7194 lbf
Max Speed 6700 rpm
Weight 811 g

Single Row Deep Groove Ball Bearings 6309-2Z/VP1760 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6309-2Z/VP1760 Bearing

6309-2Z/VP1760 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 11915 lbf, making it suitable for demanding applications.

The shielded design of 6309-2Z/VP1760 Bearing protects against dust and debris, enhancing durability.
It operates smoothly within a temperature range of -30°C to 120°C, ensuring reliability in various conditions.

With a maximum speed of 6,700 rpm, 6309-2Z/VP1760 Bearing balances performance and longevity.
The chrome steel cage maintains ball alignment, reducing wear and extending service life.

Application

Industrial Uses of 6309-2Z/VP1760 Bearing
The 6309-2Z/VP1760 Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out.
Its chrome steel construction ensures durability even in demanding environments, making it a reliable choice for continuous operation.

Where Is 6309-2Z/VP1760 Bearing Used?
You’ll often find the 6309-2Z/VP1760 Bearing in automotive applications such as alternators and wheel hubs, thanks to its ability to handle radial loads smoothly.
The metric sizing and ABEC 1 tolerance make it versatile for various vehicle designs, ensuring consistent performance.

Built for Heavy-Duty Use: 6309-2Z/VP1760 Bearing
In conveyor systems, the 6309-2Z/VP1760 Bearing excels due to its robust construction and ability to withstand high dynamic loads.
The shielded seals also help extend its lifespan by reducing dust and debris ingress, which is crucial in harsh industrial settings.

Automotive vs Industrial: Applications of 6309-2Z/VP1760 Bearing
While the 6309-2Z/VP1760 Bearing is popular in car components like transmissions, it’s equally effective in industrial gearboxes.
Its balanced performance in both high-speed and high-load scenarios makes it a go-to option across different sectors.

Perfect Fit for Automation: 6309-2Z/VP1760 Bearing
The 6309-2Z/VP1760 Bearing works well in robotic arms and automated assembly lines, where precision and reliability are key.
Its low-maintenance design and consistent performance help reduce downtime in automated systems.
