Single Row Deep Groove Ball Bearings 6308 MC/P52

The 6308 MC/P52 is a single-row deep groove ball bearing with a 40mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 915 lbf and operates smoothly at speeds reaching 7500 RPM.

Its open design allows for easy lubrication, while the machined metal cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 620g, it offers a balance of strength and lightness. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6308 MC/P52
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Tolerance Class ABEC 5 | ISO P5
Radial Clearance Trade No CN
Bore Dia 40 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 90 mm
Outer Dia Tolerance -0.015mm to 0
Width 23 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Machined metal
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 915 lbf
Static Radial Load 5395 lbf
Max Speed 7500 rpm
Weight 620 g
price（$） 70.758

Single Row Deep Groove Ball Bearings 6308 MC/P52 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6308 MC/P52 Bearing

6308 MC/P52 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 915 lbf, ensuring reliable performance in various applications.

The machined metal cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 7,500 rpm, it delivers consistent performance under demanding conditions.

6308 MC/P52 Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its open design allows for easy lubrication, ensuring smooth operation over extended periods.

Application

Common Applications of 6308 MC/P52 Bearing
In industrial settings, 6308 MC/P52 Bearing is widely used in electric motors and pumps due to its reliable radial load capacity and smooth operation. The open design and ABEC 5 precision make it suitable for high-performance machinery.

Where Is 6308 MC/P52 Bearing Used?
You’ll often find 6308 MC/P52 Bearing in automotive applications like alternators and wheel hubs, where its durability and precision are key. The metric sizing ensures compatibility with a variety of vehicle designs.

Optimized for Performance: 6308 MC/P52 Bearing
For automation systems, 6308 MC/P52 Bearing works well in robotic arms and conveyor belts, thanks to its high-speed capability and low friction. The machined metal cage adds extra strength for demanding tasks.

Light-Duty vs Heavy-Duty: Best Uses for 6308 MC/P52 Bearing
In consumer electronics like printers and fans, 6308 MC/P52 Bearing offers quiet and efficient performance. For heavier loads, it’s equally effective in industrial gearboxes and compressors.
