Single Row Deep Groove Ball Bearings 6307 TC/C78

Single Row Deep Groove Ball Bearings 6307 TC/C78

The 6307 TC/C78 is a single-row deep groove ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7509 lbf and operates smoothly at speeds up to 8500 RPM.
Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.
This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are common.
Weighing 457g, it balances strength and lightness. Compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6307 TC/C78
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 21 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7509 lbf
  • Static Radial Load 4339 lbf
  • Max Speed 8500 rpm
  • Weight 457 g
  • price（$） 82.62
Single Row Deep Groove Ball Bearings 6307 TC/C78 dimension drawing
Download DWG Download PDF

Features

How Does 6307 TC/C78 Bearing Reduce Friction?

6307 TC/C78 Bearing is crafted with chrome steel rings and balls, ensuring smooth operation and reduced friction.
Its single-row deep groove design enhances radial load capacity, supporting up to 7509 lbf dynamic radial load.
The open seal type allows for easy lubrication, maintaining performance in various conditions.
With a maximum speed of 8,500 rpm, it offers a balance of speed and durability.

Application

Common Applications of 6307 TC/C78 Bearing
In industrial settings, 6307 TC/C78 Bearing is widely used in machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending service life in demanding conditions.
For automotive applications, 6307 TC/C78 Bearing fits well in components such as alternators and wheel hubs, thanks to its balanced load handling and metric compatibility. Its chrome steel construction provides durability under varying temperatures and speeds.
In automation systems, 6307 TC/C78 Bearing supports smooth operation in conveyor belts and robotic arms, where precision and low maintenance are key. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.
Household appliances like washing machines often use 6307 TC/C78 Bearing for its quiet operation and long-lasting wear resistance. The simple design makes it a cost-effective choice for everyday devices.
