Single Row Deep Groove Ball Bearings 6307-J

Single Row Deep Groove Ball Bearings 6307-J

The 6307-J is a single-row deep groove ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 7509 lbf and operates smoothly at speeds up to 8500 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 457g, it’s a robust yet manageable option for various industrial uses. Compliant with RoHS and REACH standards for safe and eco-friendly operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6307-J
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 21 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7509 lbf
  • Static Radial Load 4339 lbf
  • Max Speed 8500 rpm
  • Weight 457 g
Single Row Deep Groove Ball Bearings 6307-J dimension drawing
Download DWG Download PDF

Features

Why Choose 6307-J Bearing for Precision Tasks?

6307-J Bearing features a single-row deep groove design, optimised for radial loads and smooth operation.
Its chrome steel construction ensures durability and resistance to wear in various applications.

With a dynamic radial load capacity of 7509 lbf, 6307-J Bearing handles demanding conditions reliably.
The open seal design allows for easy maintenance and efficient performance.

6307-J Bearing operates within a temperature range of -30°C to 120°C, suitable for diverse environments.
Its ABEC 1 tolerance class ensures consistent precision for industrial and mechanical uses.

Application

Common Applications of 6307-J Bearing
The 6307-J Bearing is widely used in industrial machinery, such as pumps and electric motors, where its deep groove design handles radial loads efficiently. Its open seal type allows for easy lubrication, making maintenance straightforward in demanding environments.

In automotive applications, 6307-J Bearing fits well in components like alternators and wheel hubs, providing reliable performance under constant rotation. The chrome steel construction ensures durability, even in high-temperature conditions.

For automation systems, 6307-J Bearing is a solid choice for robotic arms and conveyor belts, thanks to its smooth operation and ABEC 1 precision. Its compatibility with ISO P0 standards makes it versatile across various equipment types.

In household appliances like washing machines, 6307-J Bearing’s balanced load capacity ensures quiet and long-lasting performance. The metric sizing makes it easy to replace in most European and Asian models.
