Single Row Deep Groove Ball Bearings 6307/C3VB359

Single Row Deep Groove Ball Bearings 6307/C3VB359

The 6307/C3VB359 is a single-row deep groove ball bearing with a 35mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7509 lbf and operates smoothly at speeds up to 8500 RPM.

Its open design simplifies maintenance, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 457g, it offers a balance of strength and lightness. Compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6307/C3VB359
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 21 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7509 lbf
  • Static Radial Load 4339 lbf
  • Max Speed 8500 rpm
  • Weight 457 g
  • price（$） 6.012
Single Row Deep Groove Ball Bearings 6307/C3VB359 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6307/C3VB359 Bearing

6307/C3VB359 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 7509 lbf.
Its single-row deep groove design ensures smooth operation and efficient performance in various applications.
The C3 radial clearance allows for thermal expansion, making it suitable for higher-speed operations.
With a maximum speed of 8,500 rpm, it balances durability and efficiency in demanding conditions.

Application

Industrial Uses of 6307/C3VB359 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal allows for easy lubrication, making it suitable for high-speed operations.

Where Is 6307/C3VB359 Bearing Used?
You’ll find 6307/C3VB359 Bearing in automotive applications such as wheel hubs and alternators, thanks to its durable chrome steel construction. Its C3 clearance ensures reliable performance even under varying temperatures.

Perfect Fit for Automation: 6307/C3VB359 Bearing
In robotic arms and conveyor systems, 6307/C3VB359 Bearing offers smooth rotation and low friction. The metric sizing makes it a versatile choice for various automated equipment.

Light-Duty vs Heavy-Duty: Best Uses for 6307/C3VB359 Bearing
For light-duty tasks like household fans, 6307/C3VB359 Bearing provides quiet operation. In heavier industrial settings, its robust design handles continuous use without compromising performance.
