Single Row Deep Groove Ball Bearings 6306/32-2RS1/C4VB038

Single Row Deep Groove Ball Bearings 6306/32-2RS1/C4VB038

The 6306/32-2RS1/C4VB038 is a single-row deep groove ball bearing with a 30mm bore and 72mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 6002 lbf and operates smoothly at speeds up to 9600 RPM.

Sealed on both sides, it keeps dirt out and grease in, making it low-maintenance. The chrome steel cage adds strength, while the C4 radial clearance ensures reliable performance under varying temperatures.

This bearing is ideal for electric motors, pumps, or industrial gearboxes where radial loads are common. It works in temperatures from -30°C to 120°C and is interchangeable with SKF models.

Weighing 346g, it’s a sturdy yet compact choice. Compliant with RoHS and REACH standards, it’s safe for various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6306/32-2RS1/C4VB038
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C4
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 19 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6002 lbf
  • Static Radial Load 3372 lbf
  • Max Speed 9600 rpm
  • Weight 346 g
  • price（$） 21.879
Single Row Deep Groove Ball Bearings 6306/32-2RS1/C4VB038 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6306/32-2RS1/C4VB038 Bearing

6306/32-2RS1/C4VB038 Bearing is designed for radial loads, with a dynamic radial load capacity of 6002 lbf.

Its sealed construction protects against contaminants, ensuring smooth operation in various environments.

The chrome steel rings and balls provide durability, while the C4 radial clearance allows for thermal expansion.

With a maximum speed of 9,600 rpm, it offers reliable performance in high-speed applications.

Application

Industrial Uses of 6306/32-2RS1/C4VB038 Bearing
6306/32-2RS1/C4VB038 Bearing is commonly used in industrial machinery like pumps and electric motors, where its sealed design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

What Makes 6306/32-2RS1/C4VB038 Bearing a Preferred Choice?
In automotive applications, 6306/32-2RS1/C4VB038 Bearing works well in alternators and wheel hubs due to its radial load capacity. The C4 clearance allows for thermal expansion, making it suitable for varying temperatures.

Perfect Fit for Automation: 6306/32-2RS1/C4VB038 Bearing
6306/32-2RS1/C4VB038 Bearing is ideal for robotic arms and conveyor systems, where smooth operation is key. Its sealed design reduces maintenance needs, saving time and effort.

Light-Duty vs Heavy-Duty: Best Uses for 6306/32-2RS1/C4VB038 Bearing
For light-duty tasks like small appliances, 6306/32-2RS1/C4VB038 Bearing offers reliable performance. In heavier industrial settings, its robust design handles continuous use without issues.

Medical vs Industrial: Where 6306/32-2RS1/C4VB038 Bearing Excels
In medical devices, 6306/32-2RS1/C4VB038 Bearing provides quiet operation for equipment like centrifuges. Industrial applications benefit from its ability to handle radial loads efficiently.
