Single Row Deep Groove Ball Bearings 6304/HN3C3LD8VG201

Single Row Deep Groove Ball Bearings 6304/HN3C3LD8VG201

The 6304/HN3C3LD8VG201 is a single-row deep groove ball bearing with a 20mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3574 lbf and operates smoothly at speeds up to 14,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing just 144g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6304/HN3C3LD8VG201
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3574 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 14000 rpm
  • Weight 144 g
Single Row Deep Groove Ball Bearings 6304/HN3C3LD8VG201 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6304/HN3C3LD8VG201 Bearing

6304/HN3C3LD8VG201 Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 3574 lbf, making it suitable for various industrial applications.
The open design allows for easy lubrication, ensuring smooth operation and reduced friction.
With a maximum speed of 14,000 rpm, it delivers reliable performance in high-speed conditions.

Application

Industrial Uses of 6304/HN3C3LD8VG201 Bearing
6304/HN3C3LD8VG201 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 6304/HN3C3LD8VG201 Bearing fits well in components such as alternators and wheel hubs, providing smooth rotation under radial loads. Its chrome steel construction offers durability in demanding conditions.

For automation equipment, 6304/HN3C3LD8VG201 Bearing supports precise movements in robotic arms and conveyor systems. The C3 clearance ensures optimal performance even with thermal expansion.

In household appliances like washing machines, 6304/HN3C3LD8VG201 Bearing’s quiet operation and long lifespan make it a practical choice. The metric sizing ensures compatibility with a variety of European and Asian models.
