Single Row Deep Groove Ball Bearings 6300-RS1

Single Row Deep Groove Ball Bearings 6300-RS1

The 6300-RS1 is a compact single-row deep groove ball bearing, measuring 10mm in bore and 35mm in outer diameter, with a width of just 11mm. Made from durable chrome steel, it’s built to handle radial loads up to 1821 lbf and spins smoothly at speeds up to 22,000 RPM.

Its sealed design keeps out dust and dirt, making it low-maintenance and ideal for harsh environments. The bearing operates reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective replacement option. Perfect for applications like electric motors, pumps, or small machinery where radial loads are common.

Weighing only 53g, it’s lightweight yet sturdy, and complies with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6300-RS1
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 35 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 11 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1821 lbf
  • Static Radial Load 776 lbf
  • Max Speed 22000 rpm
  • Weight 53 g
Single Row Deep Groove Ball Bearings 6300-RS1 dimension drawing
Download DWG Download PDF

Features

How Does 6300-RS1 Bearing Reduce Friction?

6300-RS1 Bearing features a sealed design, keeping contaminants out and lubrication in for smoother operation.
Its chrome steel construction ensures durability while reducing friction during radial load applications.
The single row deep groove design enhances load distribution, improving efficiency and performance.
With a maximum speed of 22,000 rpm, it offers reliable operation in various conditions.

Application

Common Applications of 6300-RS1 Bearing
The 6300-RS1 Bearing is widely used in industrial machinery, such as conveyor belts and small electric motors, thanks to its sealed design that keeps contaminants out. Its chrome steel construction ensures durability in demanding environments.

In automotive applications, 6300-RS1 Bearing fits well in components like alternators and water pumps, where its radial load capacity and sealed protection are beneficial. The metric sizing makes it a versatile choice for various vehicle models.

For household appliances, 6300-RS1 Bearing provides smooth operation in devices like washing machines and fans. Its sealed design reduces maintenance needs, making it ideal for long-term use in everyday products.

The 6300-RS1 Bearing also finds use in small automation equipment, such as robotic arms, where precision and reliability are key. Its compact size and robust build make it suitable for tight spaces and continuous operation.
