Single Row Deep Groove Ball Bearings 6217-2Z

The 6217-2Z is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 19581 lbf and operates smoothly at speeds up to 4500 RPM.

Shielded on both sides, it keeps grease in and contaminants out, making it low-maintenance. The stainless steel cage adds durability, ensuring reliable performance over time.

With a temperature range of -30°C to 120°C, it’s suitable for various environments. Its P6 tolerance class and CN radial clearance offer precision for demanding applications.

Ideal for machinery like electric motors or pumps, this bearing is interchangeable with SKF models. Weighing 1.88kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6217-2Z
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class P6
Radial Clearance Trade No CN
Bore Dia 85 mm
Bore Dia Tolerance -0.015mm to 0
Outer Dia 150 mm
Outer Dia Tolerance -0.015mm to 0
Width 28 mm
Width Tolerance -0.2mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Stainless Steel
Lubrication Grease
REACH Compliant
Temperature Range -30° to 120 °C
Dynamic Radial Load 19581 lbf
Static Radial Load 14388 lbf
Max Speed 4500 rpm
Weight 1.88 kg
price（$） 37.62

Single Row Deep Groove Ball Bearings 6217-2Z dimension drawing

Download DWG Download PDF

Features

Why Choose 6217-2Z Bearing for Precision Tasks?

6217-2Z Bearing features a single-row deep groove design, ideal for handling radial loads with precision.
Its shielded construction protects against contaminants, ensuring smooth operation in various environments.

The chrome steel rings and balls enhance durability, while the stainless steel cage maintains alignment.
With a dynamic radial load capacity of 19581 lbf, it performs reliably under demanding conditions.

6217-2Z Bearing operates efficiently within a temperature range of -30° to 120°C.
Its P6 tolerance class ensures high precision, making it suitable for critical applications.

The grease lubrication reduces maintenance needs, extending the bearing’s service life.
At a maximum speed of 4,500 rpm, it balances performance and longevity.

Application

Industrial Uses of 6217-2Z Bearing
6217-2Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design protects against contaminants. The chrome steel construction ensures durability in demanding environments.

Key Fields for 6217-2Z Bearing
In automotive applications, 6217-2Z Bearing fits well in wheel hubs and alternators, offering reliable radial load support. Its metric sizing makes it versatile for various vehicle designs.

Where to Use 6217-2Z Bearing
For household appliances such as washing machines, 6217-2Z Bearing provides smooth operation with minimal maintenance. The grease lubrication extends its lifespan in everyday use.

What Makes 6217-2Z Bearing a Preferred Choice?
6217-2Z Bearing is ideal for automation systems, including conveyor belts, due to its consistent performance. The stainless steel cage adds extra resistance to wear and tear.

Designed for Versatility: 6217-2Z Bearing
In agricultural equipment, 6217-2Z Bearing handles radial loads efficiently, even in dusty conditions. Its wide temperature range suits both indoor and outdoor applications.
