Single Row Deep Groove Ball Bearings 6217-2Z/C3S1GJN

Single Row Deep Groove Ball Bearings 6217-2Z/C3S1GJN

The 6217-2Z/C3S1GJN is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 18884 lbf and operates smoothly at speeds up to 4300 RPM.

Shielded on both sides, it keeps dirt out while maintaining easy access for lubrication. The C3 radial clearance ensures reliable performance under varying temperatures, from -30°C to 200°C.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for industrial machinery, electric motors, or pumps where consistent radial load support is needed.

Weighing 1740g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use in various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6217-2Z/C3S1GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.200mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 200 °C
  • Dynamic Radial Load 18884 lbf
  • Static Radial Load 13916 lbf
  • Max Speed 4300 rpm
  • Weight 1740 g
  • price（$） 36.9
Single Row Deep Groove Ball Bearings 6217-2Z/C3S1GJN dimension drawing
Download DWG Download PDF

Features

How Does 6217-2Z/C3S1GJN Bearing Reduce Friction?

6217-2Z/C3S1GJN Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The shielded seals help keep contaminants out while maintaining low friction during operation.

Constructed from chrome steel, 6217-2Z/C3S1GJN Bearing ensures durability and consistent performance.
Its C3 radial clearance allows for thermal expansion, reducing wear in high-speed applications.

With a dynamic radial load capacity of 18,884 lbf, 6217-2Z/C3S1GJN Bearing handles demanding conditions reliably.
The design also supports speeds up to 4,300 rpm, balancing efficiency and longevity.

6217-2Z/C3S1GJN Bearing operates in temperatures from -30°C to 200°C, adapting to various environments.
Its shielded design minimises maintenance needs, making it a practical choice for industrial use.

Application

Industrial Uses of 6217-2Z/C3S1GJN Bearing
6217-2Z/C3S1GJN Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

Where Is 6217-2Z/C3S1GJN Bearing Used?
You’ll find 6217-2Z/C3S1GJN Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable radial load capacity. Its chrome steel construction offers durability in high-temperature environments.

Built for Heavy-Duty Use: 6217-2Z/C3S1GJN Bearing
6217-2Z/C3S1GJN Bearing works well in conveyor systems and agricultural equipment, handling heavy loads with ease. The ABEC 1 tolerance ensures consistent performance without unnecessary precision costs.

Medical vs Industrial: Where 6217-2Z/C3S1GJN Bearing Excels
In medical devices like centrifuges, 6217-2Z/C3S1GJN Bearing provides quiet and stable operation. For industrial gearboxes, its high dynamic radial load capacity makes it a dependable choice.

Practical Applications of 6217-2Z/C3S1GJN Bearing
6217-2Z/C3S1GJN Bearing fits well in household appliances like washing machines, where its shielded design prolongs lifespan. The metric sizing ensures compatibility with a wide range of European-made equipment.
