Single Row Deep Groove Ball Bearings 6213 Y/C782W64

The 6213 Y/C782W64 is a single-row deep groove ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 12859 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are predominant.

Weighing 979g, it balances strength and lightness. Compliant with RoHS and REACH standards for environmentally safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6213 Y/C782W64
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 65 mm
Bore Dia Tolerance -0.015mm to 0
Outer Dia 120 mm
Outer Dia Tolerance -0.015mm to 0
Width 23 mm
Width Tolerance -0.150mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
Lubrication Soild Oil
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 12859 lbf
Static Radial Load 9015 lbf
Max Speed 5300 rpm
Weight 979 g
price（$） 129.753

Single Row Deep Groove Ball Bearings 6213 Y/C782W64 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6213 Y/C782W64 Bearing

6213 Y/C782W64 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 12859 lbf.
Its solid oil lubrication ensures smooth operation, reducing the need for frequent maintenance.

The open design allows for easy inspection and cleaning, making it suitable for various industrial applications.
With a maximum speed of 5,300 rpm, it delivers reliable performance in demanding conditions.

6213 Y/C782W64 Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its durable construction and precise tolerances ensure long service life and consistent performance.

Application

Industrial Uses of 6213 Y/C782W64 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The solid oil lubrication ensures long service life even in continuous operation.

In automotive applications, 6213 Y/C782W64 Bearing fits well in wheel hubs and alternators, providing smooth rotation under varying speeds. Its chrome steel construction offers good resistance to wear and tear.

For household appliances, this bearing works quietly in washing machines and fans, thanks to its balanced design. The open seal type allows for easy maintenance if needed.

Where Is 6213 Y/C782W64 Bearing Used?
You’ll find this bearing in conveyor systems, where its radial load capacity keeps things moving smoothly. The ABEC 1 tolerance ensures reliable performance without over-engineering.

It’s also handy in small industrial gearboxes, where space and weight are considerations. The metric sizing makes it compatible with a wide range of equipment.
