Single Row Deep Groove Ball Bearings 6213/C3W64

Single Row Deep Groove Ball Bearings 6213/C3W64

The 6213/C3W64 is a single row deep groove ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 12859 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage adds durability. The bearing performs reliably in temperatures from -30°C to 120°C.

With a C3 radial clearance, it accommodates slight misalignments and thermal expansion. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for applications like electric motors or pumps where radial loads are common. Weighing 979g, it offers a good balance of strength and weight. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6213/C3W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 12859 lbf
  • Static Radial Load 9015 lbf
  • Max Speed 5300 rpm
  • Weight 979 g
Single Row Deep Groove Ball Bearings 6213/C3W64 dimension drawing
Download DWG Download PDF

Features

Why Choose 6213/C3W64 Bearing for Precision Tasks?

6213/C3W64 Bearing features a single-row deep groove design, ideal for handling radial loads with precision.
Its chrome steel construction ensures durability and smooth operation in various applications.

The C3 radial clearance allows for thermal expansion, making it suitable for high-temperature environments.
With a dynamic radial load capacity of 12859 lbf, it delivers reliable performance under stress.

Solid oil lubrication reduces maintenance needs while extending the bearing’s service life.
Its maximum speed of 5,300 rpm ensures efficient operation in demanding conditions.

Application

Industrial Uses of 6213/C3W64 Bearing
6213/C3W64 Bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The solid oil lubrication ensures long service life, even in demanding environments.

How Does 6213/C3W64 Bearing Improve Performance?
In automotive applications, 6213/C3W64 Bearing enhances the reliability of components such as alternators and water pumps. Its C3 clearance allows for better thermal expansion handling, making it suitable for varying temperatures.

Built for Heavy-Duty Use: 6213/C3W64 Bearing
For automation systems, 6213/C3W64 Bearing provides smooth operation in conveyor belts and robotic arms. The chrome steel construction offers durability, while the open design simplifies maintenance.

Medical vs Industrial: Where 6213/C3W64 Bearing Excels
In medical devices, 6213/C3W64 Bearing ensures quiet and precise movement in equipment like centrifuges. Its solid oil lubrication reduces friction, making it ideal for high-speed, low-noise applications.

Perfect Fit for Automation: 6213/C3W64 Bearing
6213/C3W64 Bearing is a reliable choice for household appliances like washing machines, where its radial load capacity ensures stable performance. The metric sizing makes it easy to replace in most European models.
