Single Row Deep Groove Ball Bearings 6211/LHT55VT197

Single Row Deep Groove Ball Bearings 6211/LHT55VT197

The 6211/LHT55VT197 is a single-row deep groove ball bearing with a 55mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 9757 lbf and operates smoothly at speeds up to 6300 RPM.

Its open design simplifies maintenance, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 599g, it offers a balance of strength and lightness. Compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6211/LHT55VT197
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 9757 lbf
  • Static Radial Load 6609 lbf
  • Max Speed 6300 rpm
  • Weight 599 g
  • price（$） 18.063
Single Row Deep Groove Ball Bearings 6211/LHT55VT197 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6211/LHT55VT197 Bearing

6211/LHT55VT197 Bearing is built with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity reaches 9757 lbf, making it suitable for various industrial applications.

The single-row deep groove design ensures smooth operation and reduces friction during use.
With a maximum speed of 6,300 rpm, it balances performance and durability.

6211/LHT55VT197 Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its open seal type allows for easy maintenance and inspection.

The chrome steel cage keeps the balls aligned, minimising wear and extending service life.
This bearing meets ABEC 1 and ISO P0 tolerance standards for consistent performance.

Application

Industrial Uses of 6211/LHT55VT197 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The chrome steel construction ensures durability in demanding environments.

What Makes 6211/LHT55VT197 Bearing a Preferred Choice?
Its open seal design allows for easy lubrication, making it suitable for applications in conveyor systems and gearboxes. The ABEC 1 tolerance ensures reliable performance without unnecessary complexity.

Built for Heavy-Duty Use: 6211/LHT55VT197 Bearing
In automotive applications, this bearing supports components like alternators and fans, where its static radial load capacity is beneficial. The metric sizing fits seamlessly into various vehicle designs.

Automotive vs Industrial: Applications of 6211/LHT55VT197 Bearing
While it excels in car parts like transmissions, it’s equally effective in industrial fans due to its balanced load handling. The temperature range of -30° to 120°C adds versatility.

Perfect Fit for Automation: 6211/LHT55VT197 Bearing
In robotic arms and automated assembly lines, this bearing’s smooth operation reduces friction. Its lightweight design at 599g ensures minimal energy loss in high-speed scenarios.
