Single Row Deep Groove Ball Bearings 6211 JEM

Single Row Deep Groove Ball Bearings 6211 JEM

The 6211 JEM is a single-row deep groove ball bearing with a 55mm bore and 100mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 9757 lbf and operates smoothly at speeds up to 6300 RPM.
Its open design simplifies maintenance, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.
This model is interchangeable with SKF bearings, offering a cost-effective replacement option. Perfect for applications like electric motors or pumps where radial loads are common.
Weighing 599g, it balances strength and lightness. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6211 JEM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 55 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 21 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 9757 lbf
  • Static Radial Load 6609 lbf
  • Max Speed 6300 rpm
  • Weight 599 g
  • price（$） 18.9
Single Row Deep Groove Ball Bearings 6211 JEM dimension drawing
Download DWG Download PDF

Features

How Does 6211 JEM Bearing Reduce Friction?

6211 JEM Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
Its chrome steel construction ensures durability while minimising friction during operation.

The open seal type allows for easy maintenance, enhancing long-term performance.
With a dynamic radial load capacity of 9757 lbf, it handles demanding applications efficiently.

6211 JEM Bearing operates within a temperature range of -30°C to 120°C, suitable for various environments.
Its ABEC 1 tolerance class ensures reliable precision in everyday use.

Application

Industrial Uses of 6211 JEM Bearing
6211 JEM Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for high-speed operations.

What Makes 6211 JEM Bearing a Preferred Choice?
In automotive applications, 6211 JEM Bearing fits well in wheel hubs and transmissions, thanks to its durable chrome steel construction. Its metric dimensions make it a versatile option for various vehicle models.

Perfect Fit for Automation: 6211 JEM Bearing
For automated systems, 6211 JEM Bearing works efficiently in robotic arms and conveyor belts, providing smooth movement. The ABEC 1 tolerance ensures consistent performance in precision tasks.

Medical vs Industrial: Where 6211 JEM Bearing Excels
In medical devices, 6211 JEM Bearing offers quiet operation for equipment like centrifuges. Its industrial strength also makes it ideal for heavy machinery requiring long-lasting reliability.
