Single Row Deep Groove Ball Bearings 6210-Z

Single Row Deep Groove Ball Bearings 6210-Z

The 6210-Z is a single-row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 8340 lbf and operates smoothly at speeds up to 10,000 RPM.

Shielded on one side, it keeps grease in and dirt out, making it low-maintenance. The stainless steel cage adds durability, while the P6 tolerance ensures precise fit and smooth rotation.

Suitable for temperatures from -30°C to 120°C, this bearing is versatile for various industrial uses. It’s interchangeable with SKF models, offering a cost-effective alternative.

Weighing 0.46kg, it’s a robust choice for applications like electric motors or pumps where radial loads are common. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6210-Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 8340 lbf
  • Static Radial Load 5216 lbf
  • Max Speed 10000 rpm
  • Weight 0.46 kg
  • price（$） 10.593
Single Row Deep Groove Ball Bearings 6210-Z dimension drawing
Download DWG Download PDF

Features

Why Choose 6210-Z Bearing for Precision Tasks?

6210-Z Bearing features a shielded design, protecting against contaminants while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.
With a dynamic radial load capacity of 8340 lbf, it handles demanding tasks efficiently.
The grease lubrication and stainless steel cage contribute to its long service life and low maintenance needs.

Application

Industrial Uses of 6210-Z Bearing
The 6210-Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design protects against dust and debris. Its chrome steel construction ensures durability in demanding environments.

In automotive applications, 6210-Z Bearing fits well in alternators and wheel hubs, providing smooth radial load support. The grease lubrication helps maintain performance even under frequent use.

For home appliances, 6210-Z Bearing works efficiently in washing machines and fans, offering quiet operation. Its metric sizing makes it easy to replace in various models.

Automation systems benefit from 6210-Z Bearing’s precision in robotic arms and conveyor belts. The stainless steel cage adds longevity, reducing maintenance needs.
